Summary of Contents for Solos smart glasses

Page 1 USER GUIDE...
Page 2: Table Of Contents
CONTENTS UNIT SETUP APPLICATION SETUP RIDE & RUN ACTIVITIES PROFILE, STATS & SETTINGS GROUP COMMUNICATION VOICE CONTROL NAVIGATION GHOST MODE TROUBLESHOOTING CONTENTS...
Page 3 • The LED will flash green when the unit is charging • The LED will be solid green when the unit is fully charged • Your SOLOS unit will be charged regardless of whether or not it is powered on when the USB cable is plugged in...
Page 4 FI T T IN G TH E D I SP L AY & A D J U ST ING T HE NOSE PI ECE It’s important to fit SOLOS so that it’s comfortable and you can see all of the display clearly.
Page 5 • Align the lens with the nose flap over the front of the Solos lens frame, then snap into place • It should fit over the Solos optics module Swapping interchangeable lens To remove a lens from the headset: • Detach the sides from the headset frame then •...
Page 6 S E TU P: SI G N IN O R C R E AT E AN ACCOU NT • The first time you use the app, the app will take you through setup • Begin by signing in, or by creating a new account •...
Page 7 S E TU P: P R OF IL E • Create your profile by importing from Facebook, or enter your details manually APPLICATION SETUP...
Page 8 • The app will search for nearby SOLOS headsets • Go to your iPhone's bluetooth settings • Select your SOLOS headset to begin pairing. (One of the screens will display your headset name) • Accept the pairing request on both the phone and on the headset (by pressing the main button) •...
Page 9 S E TU P: CON N EC T H EA D S E T • iPhone's Bluetooth settings will show your headset under my devices once connected. • The app will confirm when the connection is made. APPLICATION SETUP...
Page 10 S E TU P: SELEC T S PO RT • Select the sport you wish to configure first to use SOLOS Note: You can always switch sport later and the system will take you through setup for that sport. APPLICATION SETUP...
Page 11 S E TU P: CON N EC T S ENS O RS • The app will automatically search for nearby BLE or ANT+ sensors • Click on your sensors to connect them • Any connected sensors will automatically reconnect from this point •...
Page 12 S E TU P: SH AR IN G LOGIN • You can log into your accounts with Strava, MapMyFitness and Training Peaks to share your activity data automatically to those account(s) • Click on any of the platforms to login and enter your credentials APPLICATION SETUP...
Page 13 S E TU P: FI N I S H S E T U P • You have finished setup! APPLICATION SETUP...
Page 14: Ride & Run
R I DE & R UN S C R EE N This is the centre of the application and allows you to start a new activity. Select Workout button Metric List Switch between running and cycling mode Long press on a metric and scroll sideways to switch to metric of your choice List Icon Run/Ride Main Screen...
Page 15 R I DE & R UN S C R EE N : D U RIN G & AF T ER ACT IVIT Y • When you start an activity, you will see live metric updates on the Ride/Run screen • The activity will automatically be locked to prevent accidental ending of the activity.
Page 16 AC TIV ITI E S S CR E EN • When you have completed your activity, you will be taken to the Activities screen and will be presented with your activity details • You can also access the Activities section of the app by tapping the tab bar 'Activities' icon at any time to see your activity data •...
Page 17: Profile, Stats & Settings
P ROFI LE & STAT S • In the Profile section of the app you can access your profile information as well as seeing a summary of your metrics for the past week • Inside the Profile screen you can also access the Stats screen, where you can see detailed cumulative metrics for multiple time periods •...
Page 18 • In Settings you can control various elements of your experience: * Enable/Disable GPS usage * Manage the connection to your SOLOS headset and sensors • Control your ride/run settings (such as which metrics you want to see during your activity, setting targets to meet and the frequency at which the display updates) * Go to ‘Active Metrics’...
Page 19 * Ant+ Bridge update is for updates to the Cable Firmware this is not reliant on the firmware updates which is for your Solos headset. Updates for firmware and Ant+ bridge can arrive at separate times or together, you can update in any order...
Page 20 S E TTI NG S: R ID E & R UN HE A DS ET SC REENS • In Settings > Ride/Run settings you can: * Choose how you would like to display your metrics on your Solos headset, either in a single or multiple view...
Page 21: Group Communication
• When you select a group, the app will connect to that group automatically (two or more users need to be in the group to hear any audio) • You can press the main SOLOS headset button or double-tap the right side of your unit to enable/disable your microphones (to mute/unmute your channel)
Page 22 G ROU P COM M U N I CAT IO N: MANAGE GROUP S • When you enter the Manage Groups screen, you will see a list of the groups you are a member of. • You can add a new group by clicking on the icon * Give the group a name.
Page 23: Voice Control
VO ICE CO N T R OL • To enable voice control, click on Quick Settings on the Ride/Run screen and switch on the feature. There are a variety of commands you can issue, including: * “Start ride” (starts the ride) * “Show [metric name]”...
Page 24 VO ICE CO MMA N D S RIDE Ghost Ride Metrics (ensure selected in Settings>Ride Settings) Starting - Ending - Basic navigation Show Distance Start Ride Show Heart Rate Pause/Hold Ride Show Cadence Resume Ride Show Power Next/Forward Page Show Speed Previous/Back Page Show Time End/Finish/Stop Ride...
Page 25 VO ICE CO MMA N D S Ghost Run Metrics (ensure selected in Settings>Run Settings) Starting - Ending - Basic navigation Show Distance Start Run Show Heart Rate Pause/Hold Run Show Cadence Resume Run Show Pace Next/Forward Page Show Time Previous/Back Page Show Average Pace End/Finish/Stop Run...
Page 26: Navigation
NAV I GAT I ON • To access Navigation mode, click on the list icon (highlighted below). • You can select from three navigation options: * Enter Address – enter an address to reach using navigation * Follow Route – follow a saved route * Follow Ride –...
Page 27: Ghost Mode
G H OS T MOD E • To access Ghost mode, click on the list icon (highlighted below). • In Ghost mode, you can ‘race’ against a previous performance. The system will tell you whether you are ahead or behind your ‘ghost’ and by how much time/distance.
Page 28: Troubleshooting
* Once the unit says “hello”, press and hold the ‘minus’ button on your headset for about a second to remove the previous paired device(s). * Your SOLOS unit will go into ‘pairing mode’, meaning that it will cycle three screens with one showing the unit ID (for example SOLOS_##:##:##)
Page 29 This is because we use the headset as a ‘bridge’ due to most phones not containing an ANT+ radio. • If you find that a sensor you have connected/saved in the SOLOS app will not automatically reconnect, try these troubleshooting steps:...
Page 30 Bluetooth connection causing your headset to discon- nect. If this occurs, check whether you have external Bluetooth devices con- nected at the same time as SOLOS, such as earbuds or a watch. You may need to reduce the Bluetooth traffic from your phone.
Page 31 Reconnect the headset to the phone and continue your ride or run. • If the SOLOS app closes unexpectedly during a ride or run, your data will be retained when you restart the app. On start-up, the app will give you the option to view your lost data and save it (or discard if preferred).
