LoRaWAN Pulse Counter
VEGA SI-13
User manual
LoRaWAN Pulse Counter Vega SI-13 is used for reading of
values from metering instruments, such as water-, electricity
and heat meters via RS-485 and RS-232 interfaces or via
pulse inputs and further transmitting of this data to
LoRaWAN network.
Vega SI-13 can be used as a security by sending alarm signal
in case a specific contact pair is closed.
www.vega-absolute.ru

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SI-13-485 and is the answer not in the manual?

Questions and answers

Related Manuals for Vega SI-13-485

Summary of Contents for Vega SI-13-485

  • Page 1 RS-485 and RS-232 interfaces or via pulse inputs and further transmitting of this data to LoRaWAN network. Vega SI-13 can be used as a security by sending alarm signal in case a specific contact pair is closed. www.vega-absolute.ru...
  • Page 2 New photos of the appearance 29.05.2017 A little changes at the communication protocol 21.06.2017 Technical characteristics were changed Part “Vega LoRaWAN Configurator” was added, and 05.09.2017 some additions at the communication protocol 23.10.2017 Minor edits Edits concerning the field of application with meters 04.05.2018...

  • Page 3: Table Of Contents

    “Vega SI-13” tab ..................................22 5 COMMUNICATION PROTOCOL ............................24 Vega SI-13 pulse counter transmits the following types of packets ................24 VEGA SI-13 pulse counter receives packets of the following types ................26 6 STORAGE AND TRANSPORTATION REQUIREMENTS ...................... 28 7 CONTENT OF THE PACKAGE ..............................

  • Page 4: Introduction

    VEGA SI-13/User Manual INTRODUCTION This manual is designated for Vega SI-13-232 and Vega SI-13-485 pulse counters (hereinafter – the counter) manufactured by Vega-Absolute LLC and provides information on powering and activation procedure, control commands and functions of the counter. This manual is targeted at specialists familiar with installation work fundamentals for electronic and electrical equipment.

  • Page 5: Description And Operation

    LoRaWAN protocol to the gateway through wireless communication within 860-1000 MHz frequency band. In addition, Vega SI-13 can be used as a security device - all inputs can be configured as security inputs.
  • Page 6 VEGA SI-13/User Manual  DevEUI,  DevAddr,  NwkSKey,  AppSKey,  AppEUI,  AppKey. Moreover this information is repeated in the label-sticker on the housing cover in the form of a QR code. The pulse counter uses port 2 for data receiving and sending...

  • Page 7: Specification

    Mounting Clamp fastening to the support, DIN-rail, wall-mounting Vega SI-13 pulse counter is class C device (LoRaWAN classification) and has the following features: o Operation as LoRaWAN <-> RS-232 or LoRaWAN <-> RS-485 wireless modem o Query of some meters’ models...

  • Page 8: Operation

    VEGA SI-13/User Manual 3 OPERATION CONTACTS The pulse counter has 10 contacts, see table below: Contact Description Power - Power + RS-485 B RS-485 A RS-232 TX RS-232 RX Signal ground In1, In2 Pulse inputs 1 and 2 Ground “...
  • Page 9 VEGA SI-13/User Manual - reed switch (Herkon); - mechanical pushbutton; - open-collector output. Equipment with NAMUR pulse output is not supported Any input can be configured for work in the "Security" mode with special software when connected to the counter via USB. In this case, the device does not count pulses at the "Security"...

  • Page 10: Indication

    VEGA SI-13/User Manual INDICATION There is one red LED on the terminal board. The indication is only used when the device is activated in the LoRaWAN network. Meaning LED signal Linking to the network Series of short flashings The device connected to the...

  • Page 11: Initial Startup

    VEGA SI-13/User Manual INITIAL STARTUP VEGA SI-13 supports two activation methods in the LoRaWAN network - ABP and OTAA. Select one of the methods using “Vega LoRaWAN Configurator” application (See part 4). 1. ABP. After pressing the start button, the device immediately starts working in the "Active"...

  • Page 12: Connecting Via Usb

    VEGA SI-13/User Manual CONNECTING VIA USB The pulse counter can be adjusted with the "Vega LoRaWAN Configurator" application (See part 4). Before connecting the device to the computer for the first time, you must install the driver for the COM port stsw-stm32102, which can be downloaded from iotvega.com. After running the executable file VCP_V1.4.0_Setup.exe, the installer window will appear:...
  • Page 13 VEGA SI-13/User Manual In this window, you need to click Next, then Install, and then the installation will begin. When the installation is completed successfully, the following screen appears: After pressing Finish the driver is ready for operation, - it is possible to connect the pulse counter via USB.

  • Page 14: Vega Lorawan Configurator

    Next, the work of the application is considered in the “Expert” mode. INTERFACE OF THE APPLICATION The "Vega LoRaWAN Configurator" application does not require the special installation. When the executable file is launched, the window for working with the application appears.

  • Page 15: Connection To The Device

    For the connection to the device, perform the following steps: 1. Connect the USB cable to the device. 2. Start the "Vega LoRaWAN Configurator" application. 3. Click the "Connect" button in the menu on the left. The application automatically recognizes the type of device, and the device selection menu becomes inactive.

  • Page 16: Device Info" Tab

    VEGA SI-13/User Manual “DEVICE INFO” TAB The "Device info" tab displays information about the device, its current status, and also the data needed to register the device in the LoRaWAN network. ABP info - displays the data necessary to register the device in the LoRaWAN network with ABP method (Activation By Personalization).

  • Page 17: Lorawan Settings" Tab

    VEGA SI-13/User Manual Update firmware - allows you to select the firmware file from your computer's hard drive and load it into the device. The device will automatically disconnect from the configurator when the download is complete. The current version of the device firmware can be downloaded from iotvega.com.
  • Page 18 869.05 SF12 125 kHz Custom Set with «Vega LoRaWAN Configurator» application In the EU_868 and RU_868 frequency bands, only 3 channels are active by default. The device sends requests for connection to the network on this "join" channels. The remaining channels that the device should use can be transferred by the LoRaWAN network server during the device activation procedure (only OTAA).
  • Page 19 VEGA SI-13/User Manual This frequency band allows you to set up to 16 channels, as well as the frequency and speed of the second receiving window. The first three channels and the second receiving window parameters are mandatory. Without these parameters the custom frequency band will be considered empty Activation type –...
  • Page 20 VEGA SI-13/User Manual Join accept delay 1 (not displayed in the "Simple" mode) – sets the time that the device will open the first receiving window to receive confirmation for the join request from the LoRaWAN network. The second window always opens after 1 second after the first.
  • Page 21 VEGA SI-13/User Manual TX power (not displayed in the "Simple" mode) – the device RF transmitter power is adjusted to this value when sending packets to the LoRaWAN network. This option can be changed by the network server. TX datarate (not displayed in the "Simple" mode) – the device transmission datarate at which it will transfer packets to the LoRaWAN network.

  • Page 22: Vega Si-13" Tab

    VEGA SI-13/User Manual “VEGA SI-13” TAB The “Vega SI-13” tab contains the settings of the connected device. Current state – displays the current parameters of the device - the number of counted pulses at the inputs and the temperature. Input settings – allow you to change the operation of the pulse inputs from the counting of pulses to the security mode and back.
  • Page 23 VEGA SI-13/User Manual Data transmission settings – the transmission period which the packet with the current readings is transmit (See part 5, packet 1). Revision 08 – 04 May 2018...

  • Page 24: Communication Protocol

    LoRaWAN port 2 for uplink and downlink messages. In fields consisting of several bytes, the little endian byte order is used. VEGA SI-13 PULSE COUNTER TRANSMITS THE FOLLOWING TYPES OF PACKETS 1. Packet with current readings, sent regularly Size in bytes...
  • Page 25 VEGA SI-13/User Manual 4 bytes Reserve 4 bytes Reserve 3. Data packet from an external device, received via RS-232 or RS-485 interface Size in bytes Field description 1 byte Packet type, this packet = 3 2 bytes Total data size received via interface...

  • Page 26: Vega Si-13 Pulse Counter Receives Packets Of The Following Types

    VEGA SI-13/User Manual VEGA SI-13 PULSE COUNTER RECEIVES PACKETS OF THE FOLLOWING TYPES 1. Data sending to RS-232 or RS-485 interface Size in bytes Field description 1 byte Packet type, this packet = 4 array data Upon receiving this packet, SI-13 will transfer the data contained therein to the RS-232 / RS-485 interface (depending on the model).
  • Page 27 VEGA SI-13/User Manual 3. Command for an extraordinary survey of the connected meter Size in bytes Field description 1 byte Packet type, this packet = 6 1 byte Meter type. May be equal to: 1 – Single-phase electric meter Mercury 20X series...

  • Page 28: Storage And Transportation Requirements

    VEGA SI-13/User Manual 6 STORAGE AND TRANSPORTATION REQUIREMENTS Vega SI-13 pulse counter shall be stored in the original packaging in heated room at temperatures +5°С to +40°С and relative humidity less than 85%. The counter shall be transported in covered freight compartments of all types at any distance at temperatures -40°C to +85°C.

  • Page 29: Content Of The Package

    1. Vega SI-13-232 pulse counter – 1 pce. Screw – 4 pce. Factory certificate – 1 pce. 2. Vega SI-13-485 pulse counter – 1 pce. Screw – 4 pce. Factory certificate – 1 pce. Revision 08 – 04 May 2018...

  • Page 30: Warranty

    VEGA SI-13/User Manual 8 WARRANTY The warranty period for the device is 5 years from the date of sale. The manufacturer is obligated to provide repair services or replace the failed device during the entire warranty period. The consumer undertakes to comply with the terms and conditions of transportation, storage and operation specified in this user manual.
  • Page 31 VEGA SI-13/User Manual vega-absolute.ru User Manual © Vega-Absolute LLC 2017 Revision 08 – 04 May 2018...
