5
CSP Cummins Switchable Programming
EFILive's CSP custom operating systems for the Cummins ECM's allows
customers to be able to switch 'on the fly' between multiple tunes, all stored in the
ECM's flash memory. Refer to the specific user guide for your controller for
detailed instructions on how to upgrade your operating system.
 Cummins 6p7L CM2200 CSP5 User Guide.pdf

Cummins 6p7L CM2350B CSP5 User Guide.pdf

Logging Data

EFILive's Enhanced Data Logging (EDA) allows customers to log 45 individual
data parameters specifically chosen to complement tuning at up to 50 frames per
second using FlashScan V2/AutoCal Black Box Logging (BBL), V8 pass-thru
logging & V7.5 pass through logging.
EDA is only accessible to customers who upgrade to EFILive's CSP
system. Refer to the specific user guide for your controller for detailed instructions
on how to upgrade your operating system.
Factory scanning (data logging) of the Dodge Cummins ECM controllers is also
supported. Useful factory scantool data is very limited. EFILive recommends
users upgrade to CSP

FlashScan/AutoCal Capacity and Tune File Sizes

FlashScan V2 has approx. 6MB of internal memory capacity for the storage of
tune and log files. Capacity can be extended using an SD card.
AutoCal has approx. 6MB of internal memory capacity for the storage of tune and
log files.
The tune file sizes for the CMD and CME controllers are significantly larger than
existing controllers which directly restricts the number of tunes that can be stored
on FlashScan V2/AutoCal internal memory.
Controller
CM2350B (CME)
CM2200 (CMD)

Supporting Remote Customers

Due to the size of tune files, moving tunes on/off an AutoCal device will be
prevalent. EFILive recommends to those tuners using AutoCal for their end users,
that tune files are managed via the Quick Setup in order to manage device
configurations and minimize support issues.

Failed Flash Recovery Methods

In the event that an ECM fails during the flashing process, recovery methods exist
to restore the ECM.
In most instances, simply retrying the flash process will return the ECM to working
order.
In the instance where tuners apply security restrictions to a tune file, including
locking to the controller serial number, and the flash fails, you must try to recover
support@efilive.com
5
/EDA for useful scantool data.
Tune File Size
Approx. 3.5MB each
Approx. 2.5MB each
- 6 -
Cummins 2010-2018 Quick Start
5
operating
