8.
9.
10. DVI Input Connector (for compact 218 only)
English
8

Connection Ports

7
10
DVI-D VGA-In
compact 218
IR Receiver
RS232 Connector
Monitor Loop-through Output Connector
Composite Video Input Connector
S-Video Input Connector
Audio Input Connector
PC Analog signal/SCART RGB/HDTV/Component Video
Input Connector
Audio Output Connector
Kensington Lock Port
TM
6 5 4 3
Audio-In
S-Video Video VGA-Out
Audio-Out
8 9
2 1
RSS232
