Platinum PT-PNC7506BK-C Quick Setup Manual

v1
R2
PACKAGE CONTENTS
• Keyboard • 2 AA (For Mouse) • USB receiver
• Mouse • 2 AAA (For Keyboard) • Quick Setup Guide
SYSTEM REQUIREMENTS
• Windows® 10, Windows® 8, Windows® 7, or Mac OS 10.X or higher
• One available USB port
MOUSE FEATURES
ON/OFF switch Connect button
Battery indicator
DPI button/indicator
Scroll wheel
Right button
Backward
Zoom button
Left button Forward
Windows button
USB receiver
Battery cover
PT-PNC7506BK-C
WIRELESS KEYBOARD & MOUSE COMBO
QUICK SETUP GUIDE
Before using your new product, please read these instructions to prevent any damage.
KEYBOARD FEATURES
Front view
Back view
# ICON ITEM DESCRIPTION
1 Play/Pause Press to play or pause media.
2 Previous Press to select the previous media track.
3 Next Press to select the next media track.
4 Mute Press to turn off the computer's sound.
5 Homepage Press to open your default web browser and load your homepage.
6 Email Press to open your default email program.
7 Search Press to search inside apps, albums, artists, or songs.
8 My Favorites Press while in your web browser to open your favorite web pages.
9 My Computer Press to open My Computer.
10 Calculator Press to open the Microsoft calculator.
11 Caps lock Lights up when caps lock is turned on.
indicator
12 Number lock Lights up when number lock is turned on.
indicator
13 Power/
Lights up to display the keyboard's power, battery, or pairing status.
Low battery/
Pairing indicator
14 Power switch Slide to turn your keyboard on or off.
15 Connect button Press to pair your keyboard to your computer.
16 Battery cover Remove to replace the batteries.
INSTALLING BATTERIES
Mouse
1 Remove the battery cover, then remove the USB receiver from the compartment.
2 Insert two AA alkaline batteries, then replace the cover. Make sure that the + and – signs match the symbols in
the compartment.
AA batteries
Keyboard
• Remove the battery cover, insert two AAA alkaline batteries, then replace the cover. Make sure that the + and –
signs match the symbols in the compartment.
AAA batteries
CONNECTING YOUR MOUSE/KEYBOARD TO YOUR COMPUTER
1 Connect the USB receiver to an available USB port on your computer. Your computer installs the necessary drivers
automatically.
Note: Your USB receiver is inside your mouse's battery compartment.
2 Slide your mouse and keyboard' s power switches ON. Your computer automatically detects the mouse and keyboard.
If the mouse or keyboard does not work:
• Reconnect the USB receiver to the USB port.
• Press the Connect button on the bottom of your mouse or keyboard. The LED blinks while pairing, then turns off.
• Check the batteries in your mouse or keyboard
USING YOUR MOUSE
Adjusting your mouse sensitivity (DPI)
Press the DPI button repeatedly to switch between 1600, 2400, and 3000 DPI. The DPI
indicator lights up for 10 seconds:
• Bright: 3000 DPI
• Dim: 2400 DPI
• No light: 1600 DPI
Navigating with your mouse
Press forward to view the next page in your browser.
Press back to view the previous page in your browser.
Press and hold the zoom button while rotating the scroll wheel to
zoom in or out.
Press the Windows button to open the Start menu.
