Technical Drawing - Aquaglide Rockit JR Owner's Manual

ROCKIT JR
Saddle Valve
Main Valve
North Sports, Inc.
#1 North Shore Dr SE
White Salmon, WA 98672
USA
Compliant with
DIN EN-15649: 2012
Prolonged exposure to salt water can damage and/or shorten the expected lifetime
of this product. The marine environment includes many damaging elements including
corrosion, abrasion and damage from marine life such as barnacles. Regular
cleaning and rinsing with fresh water can reduce these risks. A PVC-safe antifouling
paint should be used to help protect this product against marine growth. DAMAGE
CAUSED BY EXPOSURE TO SALT WATER IS NOT COVERED BY WARRANTY.

TECHNICAL DRAWING

Boarding Area Perimeter Tube Valve
L: 290cm (114")
W: 290cm (114")
H: 110cm (43")
aquaglide.com | © 2017 Aquaglide
9
