SELECTRONIC™
Proximity Infection
Control Faucet
6055 / 6056 / 6057 Infection Control Faucet shown Installed on
American Standard 9118.111 Infection Control Sink
Certified to comply with ASME A112.18.1M
© 2011 American Standard
M 9 6 5 119 R E V. 1. 3
NOTE TO INSTALLER: Please give this manual to the customer after installation.
To learn more about American Standard Faucets visit our website at: www.us.amstd.com or U.S.
customer's e-mail us at: sensor@americanstandard.com
For Parts, Service, Warranty or other Assistance,
(855) 752-9259 (In Canada: 1-800-387-0369)
please call
Product No.'s & Options
Specifications
How to Install
Electrical Hook-up
Maintenance
FAQ,s
Replacement Parts
(In Toronto Area only: 1-905-3061093)
(In Toronto Area only: 1-905-3061093)
MODEL NUMBERS
6055.193
6056.193
6057
CAUTION: Use only American Standard
supplied cable sets. Using non-AS supplied
cables, or cutting, splicing or modifying any
components will void the warranty.
.193
1
2
2-3
4-6
7-8
9
10
Advertisement
Summary of Contents for American Standart SELECTRONIC 6055.193
- Page 1 SELECTRONIC™ MODEL NUMBERS 6055.193 Proximity Infection Control Faucet 6056.193 6057 .193 CAUTION: Use only American Standard supplied cable sets. Using non-AS supplied cables, or cutting, splicing or modifying any components will void the warranty. Product No.'s & Options Specifications How to Install 6055 / 6056 / 6057 Infection Control Faucet shown Installed on Electrical Hook-up American Standard 9118.111 Infection Control Sink...
- Page 2 Thank you for selecting American-Standard...the benchmark of fine quality for over 100 years. To ensure that your installation proceeds smoothly--please read these instructions carefully before you begin. UNPACKING All American Standard Faucets Are Water Tested At Our Factory. Some Residual Water May Remain In The Faucet During Shipping. 1.
-
Page 3: Installation
Roughing-in Dimensions GENERAL DESCRIPTION: (243mm) (127mm) 9-9/16" 5" Electronic faucet with proximity operation. Vandal resistant solid brass construction single post mounting. Operates on DC (battery) or AC permanent power. In-line strainer for solenoid is (53mm) (133mm) integral. Single inlet 3/8 compression, built-in 2-1/8"... - Page 4 MOUNT ENCLOSURE; Fig. 2 Fig. 2 21" NOTE. The illustration shows the Infection Control (533mm) FAUCET mounted on the American Standard Infection Control Sink. Faucet can be installed on almost any sink or countertop. For Faucet installation on the American Standard Infection Control Sink, see instruction sheet 14"...
-
Page 5: Electrical Installation
ELECTRICAL INSTALLATION Fig. 1 DC VERSION (BATTERY); Fig. 1 1. Remove ENCLOSURE COVER (1). Fig. 1. 2. Feed the EXTENSION CABLES (2) from the Faucet through the top of ENCLOSURE (3). Fig. 1a. 3. Install BATTERY (4) if not already installed, make sure the shape of the BATTERY (4) follows the shape of the BATTERY HOLDER (5). - Page 6 AC VERSION; Fig. 2 Fig. 2 Before opening ENCLOSURE CAUTION disconnect AC power supply. NOTE: For AC installation see Fig. 2b. Make power supply connection before mounting ENCLOSURE (1) to wall. 1. Remove ENCLOSURE COVER (1). Fig. 2. 2. Feed the EXTENSION CABLES (2) from the Faucet through the top of ENCLOSURE (3).
- Page 7 Unit #1 Unit #2 Unit #3 Fig. 3 FAUCET WIRE FAUCET WIRE FAUCET WIRE CONNECTORS CONNECTORS CONNECTORS 10 ft. EXTENSION 10 ft. EXTENSION CABLE CABLE AC POWER SUPPLY FOR AC-VERSION Fig. 3a (MULTI HOOK-UP); Fig. 3, 3a, 3b Unit #1 SENSOR NOTE: For AC installation see “AC VERSION;...
-
Page 8: Maintenance
TEST INSTALLED FAUCET Fig 1 TO ENSURE A LAMINAR WATER FLOW the air must be slowly purged from the spout. To do so, cover the SENSOR (1) while slowly opening the water supply valves. When the water flows as a solid, smooth, steady stream, uncover the SENSOR (1) and fully open the water supply valve. - Page 9 HOW TO CLEAN FILTER; Fig. 4 Fig.4 Before opening ENCLOSURE CAUTION disconnect AC power supply. 1. Remove ENCLOSURE COVER. 7/16" SOCKET 2. Close SUPPLY STOP (1) with 4mm Hex wrench. Note: Keep water flowing out of faucet while shutting off. 3.
- Page 10 GENERAL CLEANING; Fig. 6 Fig.6 1. For general cleaning use a damp, soft cloth to clean the spout and the sensor. 2. For cleaning dirt use a soft cloth with diluted dish washing detergent. Wipe the area using a wet cloth and dry using a soft cloth.
- Page 11 M 9 6 5 119 R E V. 1. 3...
