Zehntner GmbH
Testing Instruments
Gewerbestrasse 4
CH-4450 Sissach
Switzerland
Tel +41 61 953 05 50
Fax +41 61 953 05 51
zehntner@zehntner.com
www.zehntner.com
transport arrangements
never ship the unit with mounted weight
store this instruction together with the original packaging
the apparatus has to be transported in the original packaging
All warranty and liability claims for damages will be refused if the
instructions for the transport arrangements have not been observed.
Demounted nominal condition before and after transport:
knurled
screw
side frame left
last update: 10.10.2007
Instruction
version 1.0 dated 10.10.2007
ZAA 2300
Material for mounting / demounting:
weight
weight
slide
screws
knurled
screw
side frame
right
allen key
screws
page 1
Advertisement
Table of Contents
Summary of Contents for Zehntner ZAA 2300
- Page 1 Fax +41 61 953 05 51 zehntner@zehntner.com www.zehntner.com Instruction version 1.0 dated 10.10.2007 ZAA 2300 transport arrangements never ship the unit with mounted weight store this instruction together with the original packaging the apparatus has to be transported in the original packaging All warranty and liability claims for damages will be refused if the instructions for the transport arrangements have not been observed.
- Page 2 Place the right side frame to the ZAA 2300 so that the weight will fit into the weight slide, fix it with the knurled screw and afterwards fix the right side frame in the same way as the left side frame.
