Sure Power 71030i Installation Instructions

1. It is recommended that the batteries be disconnected prior to installation.
2. Mount converter in a convenient, well ventilated area. Use 16AWG wire
3. Terminal #4, #5, and #6 ("GND 12V"): Make ground connections first.
4. Terminal #7 and #8 ("SW 12V"): Using 16AWG connect both pins to 12V
5. Terminal # 3 ("IGN"): Using 16AWG connect to a switched 12V source. For
6. Terminal #9 and #10 ("UNSW 12V"): Using 14AWG connect both pins to
7. Terminal #12 ("72Vin, 80Vin, 96Vin"): Using 16AWG with a minimum
8. Terminal #1 ("GND POWER SOURCE"): Using 16AWG with a minimum
72V, 80V
96V
NOMINAL
BATTERY
BANK
EV BAT +
LITHO IN USA
71030i DC-DC CONVERTER

INSTALLATION INSTRUCTIONS

Reconnect the batteries after the installation is complete
with a voltage rating of at least 150V to connect to power source. Use
14AWG for the ground and 12V outputs.
Using 14AWG all three pins must be used for ground connection.
loads. These pins are switched On/Off with activation of Ignition, Terminal
#3.
always 'ON' operation this pin can be connected directly to 12V source.
12V loads. These terminals supply continuous 12V power.
NOTE: THE SUM OF TWO OUTPUT LOADS (12V SWITCHED AND
12V UNSWITCHED) CANNOT EXCEED 30 AMPS.
rating of 150V, connect to positive terminal of power source.
rating of 150V, connect to negative terminal of power source.
EV BAT -
1
CONVERTER CONNECTOR
12
TYPICAL INSTALLATION WITH SWITCHED & UNSWITCHED LOADS
(Total load must be less than 30A)
Usually Ignition switch is
IGNITION
already wired into vehicle
SWITCH
Use all 3 pins for GND
6
7
TO 12V SWITCHED LOADS
30
AMP
TO 12V UNSWITCHED LOADS
30
AMP
INSTRUCTION 180127A 0404
