CV#
Used For
01
2 Digit Address
Sound Time Out, 06 = Sound ends when loco ad-
11
dress is de-selected, 00=Sound stays on after loco is
de-selected
Configuration Register - Advanced or Standard
29
speed steps, 2 or 4 digit addressing, Analog Mode,
Normal direction of travel, speed tables
49
Forward Light (FOF) - Headlight
50
Reverse Light (FOR) - Reverse Light
51
Function 1
52
Function 2
58
Master Volume (F8 used for Mute) 1=min 00=max
60
Scheme 0=Steam 1=GP38 Diesel
132
Notch Rate
Steam Chuff/CAM config, 128=>EXT cam,
133
1-127=>DRIVER dia in inches
134
Steam Gear Ration Trim, 32 = 100% Ratio
135
Mute Volume
140
Prime Mover / Chuff Volume
141
Bell Volume
142
Horn/Whistle Volume
143
Time-Scattered Air Effects Volume
145
Misc Vols
146
Bell Ring Rate (1=24 milliseconds)
147
Air Drier Rate (1-about 2 seconds)
148
Compressor Run Rate
149
Air Compress On Time
Horn/Whistle Setup (Default=0, Playable Horn=1,
150
Alternate Horn=2 +128 for playable volume.)
Auto Coupler Sequence Threshold Value-Peak speed
151
to allow auto coupler/brake when direction change
occurs and F3 is ON
152
Project Author ID, Digitrax=221
153
Project ID, Steam/SD38_2
154
Steam Blow down / Safety Volume
155
Notching/Slip Mode: 00=Automatic,
© 2013 Digitrax, Inc.
— 8 —
Range
Default
Value
03
06
06
00
00
00
00
00-15
09
00-01
00
00-255
127
01-128
63
00-255
32
00-64
00
00-64
60
00-64
25
00-64
60
00-64
30
00-64
40
01-100
07
01-64
02
00-255
30
00-255
20
00-07 or
00
128-135
00-64
48
221
02
0-64
60
00
