Summary of Contents for Asuka PTA-100

  • Page 1 PTA-100 7-inch WiFi Multimedia Navi 2DIN User Manual...

  • Page 2: Table Of Contents

    Table of Contents Introduction ......................4 Quick Start Guide ..................... 5 II.1 Turning the Power On ......................5 II.2 User Interface ........................6 II.3 Common Screen Operation ....................7 III. Bluetooth ........................8 III.1 Connect to Bluetooth ......................8 III.2 Bluetooth Dialing ......................... 9 Internet Access .......................10 Mirroring ........................
  • Page 3 PRECAUTIONS IMPORTANT o ensure proper use, please read through this manual before using this product. It is especially important that you read and observe WARNINGS and CAUTIONS in this manual. Please keep the manual in a safe and accessible place for future reference. WARNINGS: (To prevent accidents and damage) DO NOT install any unit or wire any cable in a location where:...

  • Page 4: Introduction

    Introduction ASUKA PTA-100 is a revolutionary In-car entertainment product. It satisfies all users’ desire to access the internet while in car. On-line entertainment is beyond traditional broadcasting services & pre-recorded media contents; it brings you more entertaining and smarter than ever before.

  • Page 5: Quick Start Guide

    Quick Start Guide II.1 Turning the Power On 1. Turn on the ACC or IGN of the vehicles. 2. When the head unit activated, you will see a reminder after startup screen. 3. Now you can touch any icon on the screen to activate the corresponding function.

  • Page 6: Ii.2 User Interface

    II.2 User Interface User Interface Introduction  On the left side of the screen, there are three touch keys.  Home Screen...

  • Page 7: Ii.3 Common Screen Operation

    II.3 Common Screen Operation Touch  Touch the screen gently to select the item on the screen. Touch and Hold  Touch the screen and keep your finger in place until display changes allow you to drag the icon to the position you want it to be. Swipe ...

  • Page 8: Bluetooth

    1. Turn on the Bluetooth function of your mobile devices. Andriod iOS Devices 2. Select “Bluetooth” under Settings.” Select the device you want to pair. 3. When the mobile device is paired with PTA-100 successfully, the indicator on the screen will turn to orange.

  • Page 9: Iii.2 Bluetooth Dialing

    III.2 Bluetooth Dialing Dial out using keypads and contact list. Option 1 Keypads Option 2 Contact List...

  • Page 10: Internet Access

    Internet Access 1. Turn on the hotspot of your mobile device. Android iOS Devices 2. Select “WiFi” under “Settings.” 3. Wi-Fi connected.

  • Page 11: Mirroring

    Mirroring This function allows users to cast the mobile device to the screen of the head unit. PTA-100 supports two ways of Mirroring: via Miracast for Android and via HDMI for iPhone. V.1 Android Step 1: Make sure your mobile device is Miracast-compatible.

  • Page 12: Radio

    Radio 1. Scan Button 2. Add to Favorite 3. Equalizer Settings 4. Mute 5. Drag to change frequency 6. AM/FM band Switch. 7. Manual tune backward 8. Display current frequency 9. Manual tune forward 10. Searches for stations 11. Preset list button 12.

  • Page 13: Music

    VII. Music There are two options to choose to play music [USB] and [Bluetooth] Basic Music Interface...
  • Page 14 Listen to Music by Bluetooth Before selecting Bluetooth, pair PTA-100 to your mobile device. [See Page8]...

  • Page 15: Video

    VIII. Video Video Interface...

  • Page 16: Voice Control

    Voice Control Voice control system, is helpful for the drivers not to look at the screen on the road and is more convenient for the driver to use PTA-310 while driving. Pairing *After pairing the app and voice, simply “double tap” with two fingers on the screen to activate voice control.
  • Page 17 3. Click the App to start pairing. 4. Speak anything you wish the device to learn into the microphone twice For example speak: Navigation, I’m Lost, Maps …...

  • Page 18: Digital Television (Optional)

    Digital Television (Optional) Digital Television is an optional for countries except North America. Select TV icon to watch DTV DTV Interface To change language by select [Setting]...
  • Page 19 Select [CH Scan] to search for the available channels automatically Use [CH] / [CH] or Select CH List to change channels...

  • Page 20: Steering Wheel Control

    Steering wheel controls allow drivers to keep their eyes on the road. Step 1: Select [SETUP ICON] then [SWC] Step 2: Select VOL+ on PTA-100 Step 3: Press and hold the function button on the steering wheel, wait until the display shows paired.

  • Page 21: Reference

    The surface is easily scratched, so do not rub it with hard objects. XI.2 Troubleshooting What appears to be trouble is not always serious. Check the following points before calling dealers/ASUKA.  General No sound comes out of the speakers.

  • Page 22: Installation/ Wire Connection Guide

    XIII. Installation/ Wire Connection Guide XII.1 Precautions on installation and connection • Mounting and wiring this product requires skills and experience. For best safety, leave the mounting and wiring work to professionals. • Make sure to ground the unit to a negative 12 V DC power supply. •...

  • Page 23: Xii.2 Wiring Information

    XII.2 Wiring Information Color Function Color Function White Green White/Black Green/Black Grey Purple Grey/Black Purple/Black Pink BRAKE Yellow BAT+ Orange Black(Thick) Red/Black Blue/White SWC 1 Blue ANT+12V Brown REVERSE Blue/Black SWC 2 Black SWC GND Red/White...

  • Page 24: Xii.3 Installation Procedure

    XII.3 Installation procedure 1. To prevent a short circuit, remove the key from the ignition and disconnect the Negative (-) battery. 2. Make the proper input and output wire connections for each unit. 3. Connect the speaker wires of the wiring harness. 4.
  • Page 25  To improve the GPs signal reception, install the GPs antenna horizontally on a flat plane.  Do not wax or paint the cover of the GPS antenna. This may reduce the performance of the GPS antenna.  Wipe off the dirt of the mounting surface before installing the GPS antenna. ...
  • Page 26 ...

  • Page 27: Customer Service

    Customer Service ASUKA Autotronics Inc. Email: sales@asuka-autotronics.com Tel: +886 3-666-7117 http://www.asuka-autotronics.com Thanks for your support; we hope you enjoy our product. FCC Compliance Statement You are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment.
