dosatron IPK34-14 GPM Assembly Instructions

For quick priming (helpful at low water flows):
 Shut off outlet ball valve
 Insert injection hose into the chemical container
 Turn on the stainless steel ball valve (collect discharged
solution or send it to drain)

Observe the injection hose. When full, count 10 clicks

Shut off stainless steel ball valve
 Turn outlet ball valve on

For sample collection:

 Make sure the unit is primed
 Shut off outlet ball valve

Turn stainless steel ball valve on

In a clean container, collect 2.5 gallons of diluted solution

Shut off stainless steel ball valve
 Collect sample out of the 2.5 gallons and check
concentration
 Turn on the outlet valve
2090 Sunnydale Blvd.
727-443-5404
 Clearwater, FL 33765
800-523-8499
 
2015-02 LA 2011-140-GEN23_14 GPM
ASSEMBLY INSTRUCTIONS
IPK34 - 14 GPM
Industrial Plumbing Kit
For units: D14MZ2, D14MZ5, D14MZ10, D14MZ3000
Dosatron unit sold separately.
