ILDRCVA/ V1
IP20
12V/24V Constant Voltage LED Driver
Non-Dimmable
Installation Guide
Please retain for future reference
Models
ILDRCVA042 79-89-94 (20W 12VDC)
ILDRCVA041 99-51-39 (40W 12VDC)
ILDRCVA043 84-03-26 (50W 12VDC)
ILDRCVA044 14-89-40 (75W 12VDC)
ILDRCVA045 10-13-70 (100W 12VDC)
ILDRCVA046 12-15-64 (20W 24VDC)
ILDRCVA047 49-56-44 (75W 24VDC)
ILDRCVA048 63-93-49 (100W 24VDC)
Compliant to: EMC EC 2014/30/EU, LVD EC 2014/35/EU
Integral-LED.com
Integral Memory plc. London, NW10 0UF, UK.
Advertisement
Summary of Contents for ilntegral LED ILDRCVA042
- Page 1 IP20 12V/24V Constant Voltage LED Driver Non-Dimmable Installation Guide Please retain for future reference Models ILDRCVA042 79-89-94 (20W 12VDC) ILDRCVA041 99-51-39 (40W 12VDC) ILDRCVA043 84-03-26 (50W 12VDC) ILDRCVA044 14-89-40 (75W 12VDC) ILDRCVA045 10-13-70 (100W 12VDC) ILDRCVA046 12-15-64 (20W 24VDC) ILDRCVA047 49-56-44 (75W 24VDC)
- Page 2 IP20 Constant Voltage 12V/24V LED Driver Installation Guide WARNING RISK OF ELECTRICAL SHOCK. ALWAYS SWITCH OFF POWER AT THE MAINS BEFORE INSTALLING OR MAINTAINING THIS LED DRIVER IMPORTANT NOTICE • This LED driver should be installed according to the instructions in this guide and by a qualified electrical installer.
- Page 3 LED driver if required using suitable fixings (not supplied). OUTPUT (secondary) 12V/24V DC load Fig 1 Models: ILDRCVA041 (40W 12VDC) ILDRCVA045 (100W 12VDC) ILDRCVA048 (100W 24VDC) Models: ILDRCVA042 (20W 12VDC) ILDRCVA043 (50W 12VDC) ILDRCVA044 (75W 12VDC) ILDRCVA046 (20W 24VDC) ILDRCVA047 (75W 24VDC) Fig 2...
- Page 4 Type Input Output Maximum Model No Voltage Current Voltage Output Power Rating (AC) (DC) Current Rating ILDRCVA042 200-240V AC, 50/60Hz <0.23A 12V DC 1.67A ILDRCVA041 200-240V AC, 50Hz <0.30A 12V DC 3.33A ILDRCVA043 200-240V AC, 50/60Hz <0.30A 12V DC 4.2A...
