- Page 1 UGP-120WSPB 120 WATT PORTABLE SOLAR PANEL SYSTEM OWNER’S GUIDE APR18V1...
-
Page 2: Table Of Contents
Your satisfaction is our #1 priority. Please read this manual very carefully, it contains valuable information on how to properly maintain your new solar panel system. Thank You for choosing one of our Unique appliances - we hope you will consider Unique for future purchases. - Page 3 FEATURES & ACCESSORIES Convenient carry bag Made of durable polyester, this water-resistant padded bag has reinforced corners and protectors to ensure safe transportation and storage. Easy carry handle and safety fasteners Two heavy-duty safety fasteners lock the panels in the folded position for transportation and storage, while the durable, ergonomic handle allows for easy carrying.
- Page 4 COMPONENTS PARTS LIST 1. 2 folding mono-crystalline silicon solar panels with heavy-duty anodized aluminium frame 2. Heavy-duty carrying handle 3. Heavy-duty steel safety fasteners 4. Heavy-duty aluminium folding support legs 5. Automatic SMART solar controller with LED indicators 6. 10m connection cables extending from the controller 7.
-
Page 5: Function
FUNCTION The solar panel converts sunlight energy into DC electrical power and can be used to charge a rechargeable battery. This product is designed to charge 12V deep cell batteries, which are commonly used in cars, RVs, ATVs, boats and other motor vehicles. NORMAL OPERATING CONDITIONS Operation temperature: 5˚C –... -
Page 6: Required Battery Capacity
43.6*3 = 131 Ah at related discharge rate. Please note: • Solar panels and their controller are maintenance-free. • There are no user-serviceable parts in this unit. • If you have any problems, please contact Unique or the point of purchase immediately. -
Page 7: Installation & Connection
INSTALLATION & CONNECTION 1. Choosing a location Choose a secure, well ventilated location allowing for maximum sun exposure. Keep the solar panel system away from hazards such as camp fires, water, high-traffic areas, and shadows. 2. Set-Up (no tools required) A. - Page 8 INSTALLATION & CONNECTION continued 4. Connect the batteries Connect the battery clamp extension cable to the solar panel controller. The battery clamps are colour- coded, red for positive and black for negative. Be sure to connect to the correct polarity (the positive red clamp to the positive battery terminal and the negative black clamp to the negative battery terminal).
-
Page 9: Typical Battery Connections
TYPICAL BATTERY CONNECTIONS NORMAL CONNECTION PARALLEL CONNECTION SERIES CONNECTION CORRECT CORRECT CORRECT Load Load Load =12V =24V CHASSIS GROUND CHASSIS GROUND CHASSIS GROUND TYPICAL SERIES CONNECTIONS To inverter/ To accessory To inverter/ To accessory charger loads charger loads CORRECT CORRECT =24V =24V CHASSIS GROUND... -
Page 10: Incorrect Battery Connections
INCORRECT BATTERY CONNECTIONS To inverter/ To accessory charger loads INCORRECT CHASSIS GROUND To inverter/ To accessory charger loads INCORRECT CHASSIS GROUND... -
Page 11: Integrated Waterproof Smart Solar Controller
INTEGRATED WATERPROOF SMART SOLAR CONTROLLER Compatible Model: SDN-P10A WITH LED INDICATORS - SDN-P Series - 1. PV Solar Panel indicator light (green) 2. Battery indicator light (red/green) 3. Load indicator light (yellow) 4. PV connection terminal 5. Battery connection terminal 6. - Page 12 TECHNICAL PARAMETERS MODEL SDN-P10A SYSTEM VOLTAGE 12V/24V RATED CURRENT OUTPUT VOLTAGE Same as battery voltage LED INDICATORS MAX OUTPUT CURRENT 1. PV Solar Panel indicator light (green) WORK TEMPERATURE -35C 55C (-40F ~ 90F customized) 2. Battery indicator light (red/green) CONTROL MODE PWM charge mode 3.
- Page 13 SOLAR CHARGE CONTROLLER PROTECTION Load fault: In case of any short circuit or open circuit in the controller load connections, the controller will provide automatic protection, and the load indicator will flash rapidly. The system de- tects the load fault at a regular interval to determine if it has been eliminated.
-
Page 14: Safety Precautions
SAFETY PRECAUTIONS Please read this manual carefully to familiarize yourself with all instructions and precautions before using the portable solar panel system. Keep this manual in the pocket of the storage bag for future reference. Failure to follow the instructions and precautions in this manual may cause personal injury to the operator or damage to equipment. -
Page 15: Regular Maintenance
SAFETY PRECAUTIONS continued • When working with a lead-acid type battery, be careful not to short-out the battery with a metal tool or object. Remove all personal items such as watches, rings, bracelets and necklaces. Short circuits can happen and can damage such items and cause severe burns and/or personal injury. - Page 16 SOLAR CHARGE CONTROLLER TROUBLESHOOTING FAULT PHENOMENON FAULT ANALYSIS SOLUTION For PV solar panel - solar panel cables - check solar panel cables connection is - PV indicator light is dark in Connection mistake. correct or not. daytime. - cut off the solar panel cables connec- - DC Load is on In daytime tion it again.
- Page 17 SOLAR PANEL TROUBLESHOOTING PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION Solar panel is exposed to Battery is not properly connected 1. Check all connections to make sure sunlight but the charging to the solar panel or the sunlight the solar panel is properly connected to indicator is not lit.
- Page 18 SPECIFICATIONS: SOLAR PANEL SPECIFICATIONS: SOLAR PANEL UGP-120WSPB PARAMETERS TYPE Mono-crystalline MATERIAL ABS, PC, steel bracket MAXIMUM POWER 120W (2x60W) OPEN CIRCUIT VOLTAGE 22.5 V SHORT CIRCUIT CURRENT 6.67A MAX. POWER VOLTAGE MAX. POWER CURRENT 5.56A SIZE (FOLDED) L 33” x W 21.6” x D 2.75”...
- Page 19 APPLIANCE INFORMATION (manual copy - keep with your records) To make care and servicing of your solar panel easy and efficient, please record the following information for future reference: Model: Serial Number: Purchased From: Date Purchased: NOTES...
- Page 20 OWNERSHIP - This Warranty is made only to the first purchaser (“original purchaser”) who acquires this solar panel for his/her own use and will be honored by Unique Gas Products Ltd. and by the Seller. Purchaser must retain their receipt as proof of purchase date.
