Titan Controls HERCULES 702764 User Manual

www.titancontrols.net
For technical assistance call us at
1-888-80-Titan or 1-888-808-4826.
®
HERCULES
REASON TO USE A LOW VOLTAGE CONTACT MODULE:
This module is designed to interface any "120V output" to Air Conditioning/Heating "Low Voltage Control Inputs. "
Some Titan Controls Controllers have "120V outputs" (eg. Apollo
®
Atlas series controllers ... ). Should you need to control any SYSTEM whose inputs are not compatible with 120V output power,
®
you must use this module and refer to the connection diagram in the USER GUIDE of the SYSTEM you want to control.
ELECTRICAL SPECIFICATIONS:
Input: Low Power Coil - 120V AC 60HZ 0.4W
Output: Low Power Contact - 5A at 24V DC / 120V AC MAX.
• COM is the relay COMMON
• N.O. is the NORMALLY OPEN contact
• N.C. is the NORMALLY CLOSED contact
TYPICAL CONNECTION DIAGRAM:
Here is a typical connection diagram between
power to the A/C System is not shown here, only A/C control input terminals need to be connected to the
Contact Module.
Eg. A/C System similar to
many mainstream models.
LOW VOLTAGE CONTROL INPUTS ON TYPICAL HEATING OR COOLING SYSTEM:
When using the , power lines to the SYSTEM, it must be connected directly to the building electrical box. Control inputs are
Hercules
®
normally available on a SCREW TERMINAL BLOCK, each SYSTEM IN's or OUT's being identified by a letter. Typically, SYSTEM OUT
LINES will connect to the
Hercules
Typically, System OUTPUTS are connected to Hercules
OUTPUTS Description
R
24Vac Power to connect to any "INPUTS"
Rh
24Vac Power to connect to W / W1 / W2 / G
Rc
24Vac Power to connect to Y / Y1 / Y2 / G
C
24Vac Common, generally not used
Note: SYSTEM normally provides either "R" only or "Rh and
Rc". Rh is for Heating inputs (W), Rc for cooling inputs (Y).
Low Voltage Contact Module
(120V Prongs
connect to
the Coil)
Hercules
R
W
SYSTEM
Y
G
"COM" screw terminal and SYSTEM IN LINES to the
®
"COM" screw terminal.
®
Exclusively distributed by:
SunlightSupply.com
series timer, Zephyr
®
MECHANICAL SPECIFICATIONS:
Plastic enclosure dimensions: length 2 inches, width 1.5 inch,
depth 1 inch, prong length 0.65 inch
Terminal: thick Brass, Tin Plated
Screws: 6-32, length 0.25 inch
120V
60HZ
Coil
Low Voltage Contact Module and any Air Conditioning System. Main
®
N.O. COM N.C.
Typically, System INPUTS are connected to Hercules
INPUTS
Y or Y1
Y2
W or W1
W2
G
Warranty = 1 Year
PRODUCT # 702764
series controllers, Eos
®
N.O.
COM
N.C.
Hercules
MODULE
Low Voltage
Hercules
®
Contact Module To
connect into Titan Controls
Controller Outputs
''N.O." screw terminal.
Hercules
®
"N.O." screw terminal.
®
Description
Single or First Stage Cooling
Optional Second Stage Cooling
Single or First Stage Heating
Optional Second Stage Heating
Fan
series controllers,
®
Low Voltage
®
®
