Summary of Contents for JD JDI-17PLP
- Page 1 ™ 17-Gallon Low-Profile Portable Oil Drain Model JDI-17PLP Owner’s Manual 151 Snyder Ave. Barberton, OH 44203 17PLP-MAN REV 11/16...
-
Page 2: Parts List
PARTS LIST Item No. Description Qty. Low Profile reservoir Mounting Plate Handle Filter Screen Casters Caster Nuts Clevis Pin Drain Hose Ball Valve Hose Clip 3/8” Barbed Hose Fitting 1/2” x 3/8” Barbed Hose Fitting Hose Clamp Remove all parts from and check against the parts list. If anything is missing call TECHNICAL SERVICE at 1-800-433-0708. -
Page 3: Assembly Instructions
ASSEMBLY INSTRUCTIONS 1. Attach rear casters using caster nuts. (See Fig. 3) 2. Attach front mounting plate and casters using the caster nuts. Position mounting plate as shown in Fig. 2 using the caster and caster nut to secure it in place. 3. - Page 4 For Service Assistance Phone Toll Free 1-800-433-0708...
Need help?
Do you have a question about the JDI-17PLP and is the answer not in the manual?
