Apollo Accelerators Vampire 68080 Manual

Vampire 68080 Accelerators Manual
TABLE OF CONTENTS:
1) Disclaimer
2) Description
3) Hardware installation
4) Flashing the board
5) Software installation & support
1) Disclaimer
The installation of this product requires the opening of your computer. It is recommended to hire a professional if you are unfamiliar with
interventions on computer hardware. The Apollo team can under no circumstances be held responsible for any damage caused during assembly.
If you decide to do the installation yourself, be sure to check that your computer is disconnected from the power outlet before opening it. Be sure
you use an anti-static workplace. Discharge yourself of your static electricity before you start. Do not bend or force the components.
Warning: If you want to dispose of this equipment, please do not use the ordinary dust bin! Used electrical and electronic equipment must be
treated separately and in accordance with legislation that requires proper treatment, recovery and recycling of used electrical and electronic
equipment.
2) Description
The range of Vampire 68080 accelerator cards for Amiga Classic use the Apollo core which is compatible with the Motorola 68k processors while
outclassing them in performance. It also offers one of the most powerful graphic cards for Amiga Classic thanks to its digital video output.
Amiga 600 version
Attention: If you want to
EN
Expansion header
JTAG header
44-pin IDE header
Digital video out
Cyclone 3 FPGA
MicroSD card slot
CPU connector
Amiga 500 version
Attention: If you want to
