Installation Instructions for
6210-0084 USB Footswitch
The Herga USB footswitch is programmed by the user to simulate up to three simultaneous keystrokes.No software installation is required
as it will be recognised by the operating system once plugged into a USB socket Programming is done simply by setting small switches
inside the footswitch having removed the cover. (See pages 2 and 3)
• Works with the following OS: Windows™, MAC™ and Linux™
• Third party tested USB 1.1 Compliant.
• Cable length 2.5M
• Extension cables may be used as USB 1.1 is low speed and reliable.
DReference Dimensions
141
DSpecifications
• Power : 5V @ 20 mA
• Working temperature : 10~ 60ºC
• Weight : 395g
• Moulded Glass filled nylon plastic
construction
• Sealed to IPX2
• USB HID Compliant ( No software drivers
Subject to change without notice
Advertisement
Table of Contents
Summary of Contents for Herga Technology Ltd 6210-0084
- Page 1 Installation Instructions for 6210-0084 USB Footswitch The Herga USB footswitch is programmed by the user to simulate up to three simultaneous keystrokes.No software installation is required as it will be recognised by the operating system once plugged into a USB socket Programming is done simply by setting small switches inside the footswitch having removed the cover.
- Page 2 Installation Instructions for 6210-0084 USB Footswitch DSetting the Footswitch Function Release the two hinge screws with a screwdriver turning them a quarter turn and removing them. The lid will then come away revealing the switches. Find the Key (or combination of keys ) you require on the tables below and set SW1, 2 or 3 accordingly.
