1. The product description:
This product is a fan-type electric heaters, room heating is achieved through fan
forced cooling, this product can only be used in household or factory. A built-in
physical expansion type thermostat and self-reset overheat thermal cut-out adjust the
temperature and provide protection. At ambient temperature 0 ° man can adjust the
temperature of the thermostat in a range of 0-40 °C to control the air inlet
temperature; the self-reset thermal cut-out controls the appliance body temperature,
so that to avoid the overheating caused by wrong operation and provide the user a
safety and secure operation. The cooling fan is not controlled by thermostat and still
works when the heating element was power-off. The Product can be adjusted
upwards with an angle up to 10-degree, it's user-friendly for heating with different air-
outlet angles; a built-in anti-overturn switch shuts off the heater when it was tipped
over 50-degree or above and the product stopped working.
GENERAL SECURITY :
This device is not intended for use by persons (including children) with physical, sensory or
mental disability, or persons lacking experience or knowledge, unless supervised by a person
responsible for their safety, supervision or instruction concerning use of the device.
You must watch children to make sure they do not play with the apparatus.
HEATING « RED HOT VARIO »
Ref 93477
User's Manual - GB
Advertisement
Table of Contents
Related Manuals for Romus RED HOT VARIO
Summary of Contents for Romus RED HOT VARIO
- Page 1 HEATING « RED HOT VARIO » Ref 93477 User’s Manual - GB 1. The product description: This product is a fan-type electric heaters, room heating is achieved through fan forced cooling, this product can only be used in household or factory. A built-in physical expansion type thermostat and self-reset overheat thermal cut-out adjust the temperature and provide protection.
- Page 2 This device may be used by children aged 8 years or older and by persons with reduced physical, sensory or mental capacities or lack of experience or knowledge if they are properly supervised) S or if instructions for the safe use of the device have been given and the risks involved have been taken into account.
- Page 3 Electric connection: through coupler and plug 2. Product description and operation: ⑴ handle ⑵ switch knob ⑶ thermostat ⑷ front cover ⑸ steel frame ⑹ angle orientation plate ⑺adjustment knob ⑻ rear cover ⑼ motor Control Panel...
- Page 4 Rotary switch with 3 levels and 4 positions, the first level is ventilator only, the second level is 2KW heating power，and the third level is highest power 3KW。 0～40C adjustable thermostat to control the room temperature，the thermostat button can be turned from 0 to 270 degree. THERMOSTAT INSTRUCTIONS At first turn the thermostat to “Max”...
- Page 5 During the operation the user can increase the air out-let angle, the biggest adjustment is 14 degrees. Firstly tighten the adjustment knob at both ends of steel- pipe rack then gently press the tail top of the product with hand, the heater will be tilted.
- Page 6 physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. 17) Children should be supervised to ensure that they do not play with the appliance. Cleaning and maintenance Before cleaning the appliance, disconnect it from the socket and let it cool down.
- Page 7 This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact the retailer where the product was purchased.
