- Page 1 USER INSTRUCTION MANUAL SAPPHIRE SERIES 1100 & 1100EC Read Entire Manual Before Operating Device OI-S1100401-401.5 Uncontrolled Document Rev. 6.0 - 06/23/2006...
-
Page 2: Table Of Contents
Return/Exchange Goods Policy Warranty Provisions Technical Description of the Equipment: The two principle components of the Sunflower Medical Sapphire Series 1100 & 1100EC Mattress System are a specialized air inflatable bladder (Air Mattress) and an electrically powered, Air Blower/Control Unit. -
Page 3: General Warnings And Precautions
GENERAL WARNINGS AND PRECAUTIONS WARNINGS WARNING: DO NOT use this device if the power cord is cut, frayed or loosely connected to the device. WARNING: Make sure power cord is plugged into a properly grounded A/C 110V outlet. PRECAUTIONS CAUTION: DO NOT use around an open flame. CAUTION: The housing of the master control unit should only be opened by qualified technical personnel. -
Page 4: Description Of The Device
DESCRIPTION OF THE DEVICE: The Sapphire Series 1100 & 1100EC Mattress Replacement System consists of a control unit, power cord, a Low Air Loss Mattress and a waterproof, vapor permeable, easy-to-clean cover. UNPACKING / PARTS BREAKDOWN: Parts Air Blower/Control Unit Power Cord (hospital Grade) True Low Air Loss Mattress Replacement Mattress Cover... -
Page 5: Operating Instructions
Sapphire Series 1100 & 1100EC Operating Instructions: 1) Remove standard mattress from the bed. 2) Replace standard mattress with the Sapphire Series 1100 or 1100EC mattress. (Be sure air tubing is at the foot end of the bed.) 3) Strap air support mattress to bed frame on all four sides. 4) Place control unit on the footboard of the bed using the two retractable hooks located on the back of the unit. - Page 6 13) Alternating Mode a. Press the Alternating Mode button b. Set the desired cycle time with Cycle Time buttons (3-20 minutes) c. Set the desired comfort level with the Soft/Firm buttons. 14) Lock-out Feature a. After 3 minutes, if there are no changes to the blower settings, the lockout feature will activate.
-
Page 7: Key Pad Quick Reference
Mode - Press to switch Soft/Firm Settings – between Alternate and Firm - Adjusts surface Static operations. toward firmer level. Static – Increases airflow. Enables static Soft - Adjusts surface low-air-loss toward softer level. therapy. Decreases airflow. Alternate – Enables alternation with pressure sensors regulating airflow. -
Page 8: Mattress And Blower Unit Cleaning
MATTRESS CLEANING INSTRUCTIONS: CAUTION: A. It is recommended that gloves and protective clothing be worn at all times during cleaning and disinfecting B. Hypercarbonate and phenol based solutions should not be used. During Operation: For normal soil, wipe down cover and interior sacs with a standard cleaning disinfectant and wipe off excess moisture with a towel. -
Page 9: Maintenance
Maintenance: Foam air filter on the back of the control unit must be cleaned weekly periodically with warm soap and water. Replacement of the foam filter is recommended every 6 months. Storage: Deflate mattress using the CPR valve until all air is exhausted completely. -
Page 10: Frequently Ordered Parts
Frequently Ordered Parts The following is a list of parts that are frequently ordered for self replacement and repairs. To aid you in ordering parts, please use the provided product numbers given below for each part. The replacement of some parts not listed here may require sending in the unit to the manufacturer for repairs. -
Page 11: Return/Exchange Goods Policy
Service Department. Once RAN is issued, customer must return all items placed on the RAN within five working days from the date of the RAN to Sunflower Medical LLC. Without an Authorized RAN, all items will be returned to the customer at the customer’s expense.
