AS-100P ANCHOR
INSTALLATION INSTRUCTIONS
SRS Australia
PTY LTD
12 Enterprise St
Richlands QLD 4077
Australia
Phone 07 3812 2283 Fax 07 3812 1187
Info-au@srsmith.com
www.srsmith.com/au
S.R. SMITH, LLC
CORPORATE HEADQUARTERS
P.O. Box 400 • 1017 S.W. Berg Parkway
Canby, Oregon 97013
USA
Phone (503) 266 2231 • Fax (503) 266 4334
www.srsmith.com
06-252
S.R. SMITH, LLC 2006
OCT 14
Advertisement
Table of Contents
Related Manuals for S.R.Smith AS-100P
Summary of Contents for S.R.Smith AS-100P
- Page 1 Phone 07 3812 2283 Fax 07 3812 1187 Info-au@srsmith.com www.srsmith.com/au S.R. SMITH, LLC CORPORATE HEADQUARTERS P.O. Box 400 • 1017 S.W. Berg Parkway Canby, Oregon 97013 Phone (503) 266 2231 • Fax (503) 266 4334 www.srsmith.com 06-252 S.R. SMITH, LLC 2006 OCT 14...
- Page 2 Introduction The AS-100P 48mm/1.90in OD x 15.25cm/6in deep universal anchor system can be used for any of S.R. Smith’s products that require a 48mm/1.9in diameter anchor. A 5cm/2in spacer is included for products that only require a 10cm/4in deep anchor socket.
- Page 3 If the concrete thickness is less than the required depth of the hole, proceed to Step 2. Otherwise, go to Step 3. Installation Step 2 If the depth of the concrete is less than the depth of the hole required for installation, remove base/fill material below the concrete (18cm/7in total depth recommended) sufficient to fit the anchor.
