• When using your Jukebox Wizard with your mobile phone and a call
comes in- the speaker will pause your music and your stereo will emit
a ringing tone
• The call can be answered by pressing the function button once
Redial the last calling number:
1) No music, just press the key twice swiftly to redial the number;
2) if you're playing music, press once to pause the music first, and
press twice swiftly to redial.
Ring off, press the key once to resume the music playing
NOTE: The LED will flash red if no signal is received from your mobile
phone after 3 minutes.
Hold the function
key to cycle the modes between standby and
working. No need use the main Power switch on the right. Hold the function
key about 5S, the LED indicator on front will go out, and the speak is
automatically in standby mode. Continue in the same way to resume the
working status.
Note: If the system is not used for an extended period of time, the system
will enter the battery protection mode to protect the battery power. To
resume working status, please turn off the main power switch on the right,
and connect to a computer or any other standard USB port to activate it.
When storing it for a long time without use, please turn off the main power
switch. Then the system can not enter the battery protection mode.
The Bluetooth
word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and
®
any use of such marks by Innovage,LLC. is under license.
Other trademarks and trade names are those of their respective owners.
How to Answer a Call
Setting up Standby Mode
The Jukebox Wizard is a small speaker device with big sound and
connects to your mobile phone or tablet device via Bluetooth
Jukebox Wizard with the included USB cable for hours of musical
enjoyment anywhere you go. Use your Jukebox Wizard as a speakerphone
instead of your phone for clear and convenient group participation.
Initially, the battery is not full charged. It needs to be fully charged to power
the Jukebox Wizard.
1. Put the speaker on a stable surface.
2. Plug USB cable to 3.5 DC Jack interface of speaker's power supply and
other end into USB outlet. The power button LED indicator turns RED while
charging. Let Jukebox Wizard fully charge 3.5 hours until the LED indicator
light turns GREEN. Use the included cable ONLY.
Amplifier:
Input port (data): Bluetooth
2.4 G wireless digital transmission input
®
Input port (imitation): Stereo L/R; 3.5mm Stereo Mini Plug
Output power (trends): 2.5W x 2 ( 1 kHz,1% THD)
Output power (Maximum instantaneous): 3W x 2 ( 1 kHz, 10% THD)
AUX3.5mm Line input impedance : 4.7kΩ
Input sensitivity: 560mV
Power supply: Built-in lithium polymer 3.7V 1500mAH
Charging: USB interface, charge Current: 750mA, charge time: 3.5 hours
Bluetooth
®
Specification of Bluetooth
®
: Version 2.1+EDR
Online distance of Bluetooth
: Appro.10M
®
Type of Speaker: Stereo ( Passive radiation technology)
Speaker Unit : 4.5cm full-range tapered unit 4Ω 3W
Frequency Response : 90Hz-20kHz
Separation Degree : ≥45 dB
INSTRUCTION MANUAL
. Charge your
®
Before you Start
Specifications
