LibraCELL
Product Manual
Manual Version 1.6.5
© 2017 Kinesys Projects Ltd

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LibraCELL and is the answer not in the manual?

Questions and answers

Summary of Contents for Kinesys LibraCELL

  • Page 1 LibraCELL Product Manual Manual Version 1.6.5 © 2017 Kinesys Projects Ltd...
  • Page 2 LibraCELL © 2017 Kinesys Projects Ltd All rights reserved. No parts of this work may be reproduced in any form or by any means - graphic, electronic, or mechanical, including photocopying, recording, taping, or information storage and retrieval systems - without the written permission of the publisher.

  • Page 3: Table Of Contents

    Power On Part 3 Factory Defaults Part 4 The Default Display Part 5 Operation Part 6 Editing A Parameter Via The Keypad Part 7 Connections Part 8 Adjusting The Zero Offset Part 9 Contact Information © 2017 Kinesys Projects Ltd...

  • Page 4: Part 1 Introduction

    This document covers LibraCELL software version 3.23. The LibraCELL is available in two types the 3.25T or the 4.75T. They feature a digital data connection as well as an onboard load readout (available in lbs or kg) on a highly visible LED display with an easy to use menu system.

  • Page 5: Factory Defaults

    Factory Defaults Factory Defaults If a LibraCELL is powered up with the 'M' button pressed, it will revert back to factory defaults. Calibration and offset settings will be preserved. The Default Display The default display menu will show the current load in kg. The activity indicator in the top corner of the display will flash once a second to indicate that the cell is working.
  • Page 6 Using different bows and load pins together can result in the LibraCELL producing less accurate readings. 2. The Crosby and Kinesys logos should be on the same side of the LibraCELL. LibraCELLs that feature a 5 digit unique identifier tag, will be on the inside of the bow.

  • Page 7: Part 6 Editing A Parameter Via The Keypad

    A LibraCELL with the nut correctly tightened. 4. Ensure that when the LibraCELL is in use the points the it is picked up from (the top of the bow and center of the bobbin) are aligned vertically. If the loads on the LibraCELL are at an angle then this can cause incorrect or inaccurate readings to be given.

  • Page 8: Part 7 Connections

    Digital connections are made via the 4 Pin XLR connectors mounted on the side of the LibraCELL. LibraCELLs are designed to be daisy chained, and they provide a XLR4 input port and an XLR4 output port. DO NOT CONNECT THE XLR4 PORT OF A LIBRA CELL DIRECTLY TO AN ELEVATION.

  • Page 9: Adjusting The Zero Offset

    Elevation. Due to limitations within the Elevation this is not the recommended way of Linking a LibraCELL to an Elevation. It is recommend that a LibraPRO is used whenever possible. The analogue input of the Elevation is low resolution input and accepts an input voltage between 0 and 5V.

  • Page 10: Contact Information

    LibraCELL Contact Information If you would like to get in touch with Kinesys then please use any of the following methods. Email: info@kinesys.co.uk Website: www.kinesys.co.uk Tel: +44 (0) 20 8481 9850 Fax: +44 (0) 20 8487 0396 Mail: Unit 2 Kempton Gate Business Centre...
