FiveO GS Owner's Manual

Mini array series 4" two-way passive system

Advertisement

Quick Links

MINI ARRAY SYSTEM
4" Two-way passive system
GS / DF12P / DF12A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GS and is the answer not in the manual?

Questions and answers

Summary of Contents for FiveO GS

  • Page 1 MINI ARRAY SYSTEM 4" Two-way passive system GS / DF12P / DF12A...
  • Page 2 Important Safety Instructions - 2 -...
  • Page 3: Table Of Contents

    Table of Contents 1. INTRODUCTION 2. INSTALLATION TIPS 3. USEFULL DATA 4. QUICK START 5. SATELLITE LAYOUT OF THE CONNECTOR PANEL 6. SATELLITE BACK PANEL DESCRIPTION 7. SATELLITE DOWN CONNECTION 8. SATELLITE UP CONNECTION 9. SUBWOOFER BACK PANEL DESCRIPTION 10. TECHNICAL SPECIFICATIONS 11.
  • Page 4: Introduction

    Introduction Thank you for choosing the new ARRAY SERIES cabinets have been designed to provide a cost effective high grade solution while maintainig high quality cabinet construction and optimum components. The array series, can be used for all types of applications including, but not limited to, churches, conference centers and discos.
  • Page 5: Quick Start

    Quick Start When mounting a speaker onto any stand, always ensure that the stand is on a flat, level surface, with the legs fully extended. Be sure to check that the maximum load weight for the stands is greater than the weight of the ARRAY SYSTEMS loudspeaker. Never use a stand with a maximum load weight lower than the speaker.
  • Page 6: Satellite Layout Of The Connector Panel

    Satellite Layout of The Connector Panel One module * Option wall bracket The direction of the bracket can be adjusted from any side. More module Versatile mounting options Compared to many other speaker designs, the satellite Series is remarkably easy to install in several ways.
  • Page 7 Satellite Layout of The Connector Panel Connect Manner Align two units to make the latch hole in the same line. Insert the latch and lock the screw tightly. Adjust the angles of the unit (four angles: 0°-4°-8°-12 can be adjusted), insert the rear connecting pin into the related slot and put the latch into the hole.
  • Page 8: Satellite Back Panel Description

    Satellite Layout of The Connector Panel Minimal reflective effects Whether mounted on the wall or ceiling, the satellite is remarkably free from the comb filter and interference effects often encountered with other speaker designs. It can therefore produce more low frequency output even when mounted on the wall or ceiling. Satellite Back Panel Description 1) INPUT: Receive the power coming from an external power amplifier.
  • Page 9: Satellite Down Connection

    Satellite Down Connection INPUT 1 Module.array. (8.ohms) Module 1: INPUT 2 Module.array. (4.ohms) Module (1-2): INPUT 4 Module.array. (8.ohms) Module (1-3): INPUT Module (2-4): 6 Module.array. (5.33.ohms) Module (1-3-5): INPUT Module (2-4-6): 8 Module.array. (4.ohms) Module (1-3-5-7): Module (2-4-6-8): - Power output for satellite speaker down connection - 9 -...
  • Page 10: Satellite Up Connection

    Satellite Up Connection INPUT INPUT INPUT INPUT INPUT 1 Module.array. (8.ohms) Module 1: 2 Module.array. (4.ohms) Module (1-2): 4 Module.array. (8.ohms) Module (1-3): Module (2-4): 6 Module.array. (5.33.ohms) Module (1-3-5): Module (2-4-6): 8 Module.array. (4.ohms) Module (1-3-5-7): Module (2-4-6-8): - Power output for satellite speaker UP connection - 10 -...
  • Page 11: Subwoofer Back Panel Description

    Subwoofer Back Panel Description INPUT: Receive the power coming from an external power amplifier. (SPK +1/-1 connected; +2/-2 not connected). OUTPUT: Power output for satellite speaker, under passive crossover filtered at 180 Hz. (SPK +1/-1 connected; +2/-2 not connected). Speakon Parallel Socket - 11 -...
  • Page 12 This setting can be performed by a PC via LAN port, using a router for internet. This “preset” comes from factory set with the parameters of the 4*GS, after making the necessary changes you can be save into the system.
  • Page 13: Technical Specifications

    Technical Specifications satellite Line Array: Indicates number of amp ch $ impedance (per ch) Multiple modules connected in series (+) & parallel (//) See patch sketches in "Powering your mini line array. Array Power Single channel configuration Rating(AES) 1 module array 1ch 8 ohms 2 module array 1ch 4 ohms (2//)
  • Page 14 Technical Specifications Model Active DF12P System Type 12"Passive Vented Subwoofer Rated Power 300W Program, 600W Peak @ 8 Ohm Sensitivity 122dB Continuous / 125dB Peak Frequency Response 45Hz-2.8kHz (-10dB) Impedance 8 ohms Transducer Low 12" (320mm)Ferrite Woofer, 2.55" (64.5mm) Voice Coil Connector 4 PIN Terminal Block and 2*NL-4 Speakon Parallel Socket Enclosure Construction...
  • Page 15: System Connection Plate

    System Connection Plate Make your initial connections with all the equipment powered off, and ensure that all the main volume controls are turned completely down. For Passive Full-range Speaker Cabinet 1) Connect one side of the speaker cable to the Output CH A / CH B to Binding Post of your stereo power amplifier and the other side to the Input socket of your speaker cabinet.
  • Page 16 System Connection Plate Speaker Cable-R Speaker Cable-L Stereo Power Amplifier Satellite Satellite Left / Right DSP control cable Main Output Mixer Subwoofer Subwoofer - 16 -...
  • Page 17 System Connection Plate Make your initial connections with all the equipment powered off, and ensure that all the main volume controls are turned completely down. Two Active Subwoofers & Two Passive Satellite Speakers 1) Connect one side of the signal cable to the output of your mixer (left / right) with a TRS or XLR connector and the other side of the cable to the line input (combo) in the active subwoofer (with a TRS to XLR connector).
  • Page 18 System Connection Plate Line Line Input Input Satellite Satellite Subwoofer Subwoofer Mixer - 18 -...
  • Page 19: Wire Connections

    Wire Connections Either the 1/4" TRS phone jack or XLR connector can be wired in balanced and unbalanced modes, which will be determined by the actual application status, please wire your system as the following wiring examples: The series speaker connections are made via the rear panel 1/4" and/or Speakon connectors for easy interface with industry standard cables.

This manual is also suitable for:

Df12pDf12a
