Hoselink 6567 Assembly Manual

Saw blade assembly instructions

Step 1:
Gather saw blade, bolt, spring washer and butterfly nut.
Step 2:
Place the bolt into the back side of the frame to fit the
square hole. Put the blade on the front side of the frame.
For more information visit www.hoselink.com.au or call 1300 900 617

Kit contents

1x High carbon teflon coated blade
1x Efficient 4 Pulley gearing system
1x Durable nylon coated pulley cord
1x Innovative nylon safety lock feature
1x Telescopic handle
Step 3:
Secure the blade with the butterfly nut and spring
washer provided.

Extension instructions

Steps:
1. Move the locking latch upward.
2. Push the toggle switch upward.
3. The length of the tool may now be adjusted.
Push the internal tube forward.
1
3
2
Assembly guide
Pole Pruner
Item: 6567
