LogicMark FreedomAlert Installation Manual page 2

1
Place Batteries in Base
_ _
+ +
Master
ON/OFF
Switch
RED Light = Charging
GREEN Light = Battery Charged
No Light = Defective battery or no battery installed
2
Place Battery in Pendant
Install one pendant battery in pendant.
(When battery is properly installed, pendant
will automatically perform a battery check.
Listen for these voice prompts every time a
battery is installed.)
**Battery should standby in the pendant for
4-6 months (depending on use). We recommend
exchanging/charging the batteries monthly.
**911 Forwarding Feature - If the contact deems the situation to be a true emergency, they simply press 911 on their keypad. The FreedomAlert will
hang up with them and dial 911. The person having the emergency will then be able to speak to the 911 Emergency Operator.
Step-by-Step Installation
If you need assistance, call
1A. Place the Green AA Rechargeable
Batteries in the compartment on the
bottom of the base unit. Check the picture
for correct orientation.
1B. Turn ON/OFF switch to ON. You will
hear the announcement "Running on
Battery Power." Unit will do so until the
AC Adapter power supply is plugged in.
1C. Place one pendant battery in the
Pendant Battery Charger on the front
of the base. The charging light key is as
follows:
Pendant battery
compartment
3
1-800-519-2419
A. Plug the AC Adapter
power cord into the power
jack and twist 1/4 turn
clockwise to lock.
B. Plug the AC Adapter
into an electrical outlet.
4
Perform a System Test
a. Push GRAY test button on back of pendant for 4 seconds.
b. Listen for voice prompt from base unit:
i. "All Systems are OK – Battery is OK" is heard if the system is correctly installed.
ii. If any other voice prompt is heard, the unit will describe the problem.
c. We recommend that you perform this System Test weekly.
Place a call:
a. Push the BLUE EMERGENCY button for 2 seconds on Pendant. (The RED
LED on the pendant should turn ON.)
b. You should hear a dial tone and dialing as it calls your contacts or
911. Several seconds later you will hear the announcement, "This is an
emergency. If you would like to continue, please press 5..." Your contact
should press 5, and all dialing will then stop.
c. Talk normally into the pendant– just like into a speaker phone.
d. At the end of the conversation, push the GRAY TEST BUTTON for to hang
up. The contact can also press 9 to hang up. (The FreedomAlert will
automatically hang up after 3 minutes of silence.)
Model
#35911
Plug Telephone Line and Power
Cord into Wall Jacks
(OPTIONAL) Plug the
telephone into one of
the telephone jacks.
Test the Unit
Plug the telephone
cord into the jack and
then plug the System
in to a wall or modem
telephone jack.
