Summary of Contents for Sirman SIGIX M20
- Page 1 Tray thermo-sealer CE professional SIGIX M20 SERVICE CENTRE AUTHORISED DEALER Instruction Manual, for Use and Maintenance...
- Page 2 To proceed with the cleaning of the machine from the outside, use a slightly ATTENTION! soaked sponge with a small quantity of detergent and an odourless and non- harmful sanitizer. Do not use abrasive detergents, anti- scaling detergent creams, solvents and diluents;...
- Page 3 FOREWORD CHAP. 10 – ISSUES AND SOLUTIONS (See Fig. n°33) This manual has been drafted in order to provide the Customer with all the information 10.1 – POSSIBLE ERRORS on the machine and on the relating safety regulations, as well as all use and maintenance instructions, allowing to use the means in the best way possible, preserving efficiency intact in the course of time.
- Page 4 3. Pull the film correctly above the tray to seal (Fig. n°29-30). CHAP. 9 – USE OF THE MACHINE page 15 PAY ATTENTION to the knife for the cut of the film! - STARTING THE MACHINE 9.1.2 - Setting the use parameters 9.1.3 - Sealing –...
- Page 5 The sealer displays the status of the CHAP. 1 – THE MANUAL machine (a), the time for the sealing 1.1 - PURPOSE of the tray (d), the preset temperature The purpose of the Manual consists in providing the instructions as well as the (b), the current temperature of the STOP 175°...
- Page 6 8.2 – PRELIMINARY CHECKS CHAP. 2 – INFORMATION ON THE MACHINE Before proceeding with the testing, place the film correctly (see par. n°8.1), then, 2.1 – GENERAL PRECAUTIONS test the functioning with the following procedure (see Fig. n°23): Although they may seem predictable, the general precautions are essential for turn on the machine by selecting the general switch “ON/OFF”...
- Page 7 which may ruin the surfaces, do not CHAP. 8 – USE OF THE MACHINE dip it in water or in other liquids. Do not leave the machine exposed to 8.1 – POSITIONING OF THE FILM (See Fig. n° 21) harmful agents: sun, rain, sprays, ATTENTION! use only sealable film.
-
Page 8: Warning Signs
3.2 – WARNING SIGNS CHAP. 7 - INSTALLATION 7.1 – POSITIONING The surface, on which the machine must be installed, must take into account the Danger label, showing the achievement of high temperatures bearing sizes, shown on Tab. 1, and, therefore, have a sufficient width; it must on the welding plate. - Page 9 CHAP. 6 - TECHNICAL DATA CHAP. 4 – ABOUT THE MACHINE 4.1 – CONSTRUCTION FEATURES 6.1 – SIZE REQUIREMENT, WEIGHT, FEATURES ... The machine mainly consists in a stainless steel structure AISI 304, whereas the welding plate consists in Teflon-coated aluminium. 4.2 –...
- Page 10 CHAP. 5 – TRASPORT PACKAGING AND UNPACKAGING WARNING! 5.1 – PACKAGING The packaging, in which the machine is shipped, is made up of (Fig. n°10): Do not stack up more than two cardboard box, protection nylon mate- packagings. (Fig. n°14). rial and cardboard inserts.
