SA2-004 Installation Guide
SwitchAir Active Network Switch Cooling
Effective cool air delivery for rear rack mounted switches
with front (port) air intake.
Installation Precaution:
•
Install SwitchAir such that the required airflow for safe operation of equipment is not compromised.
•
Take precaution to avoid interference with the switch input power cords when installing on a live unit.
SwitchAir Installed in Rack
Installs in minutes while network switch is live.
Rail Depth Range
Chassis Depth
Channel Depth
Input
Power/Indicator
Input Connector
geistglobal.com
SA2-004 Specifications
26 5/8" to 29 5/8"
9"
26"
90-264 VAC 50/60Hz
15 watts
LED Power Indicator
C14
Airflow
Switch Intake/Exhaust
Safety/Approvals
Warranty
94 CFM
Front/Rear
UL, cUL 60950, CE,
FCC Class A
Two Years
GM1180
Advertisement
Table of Contents
Summary of Contents for Geist cool SwitchAir SA2-004
- Page 1 SA2-004 Installation Guide SwitchAir Active Network Switch Cooling Effective cool air delivery for rear rack mounted switches with front (port) air intake. Installation Precaution: • Install SwitchAir such that the required airflow for safe operation of equipment is not compromised. •...
- Page 2 Installing the SwitchAir (1) A The channels attach to the inside of the rack using cage nuts and screws. The front side channels use the top and bottom holes for their attachment. The rear channels are supported by the stabilizing tabs that attached to the air trunk.
