BORIS
the comfortable toilet and shower chair
Instructions for use

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the boris and is the answer not in the manual?

Questions and answers

Related Manuals for Schuchmann boris

Summary of Contents for Schuchmann boris

  • Page 1 BORIS the comfortable toilet and shower chair Instructions for use...
  • Page 2 Please note that guidelines and representations in these Instructions for use may deviate from your product due to differing equipment. We reserve the right to make technical modifications. Important information! Ensure that these Instructions for use remain with the product. Your Schuchmann Team...

  • Page 3: Table Of Contents

    Contents Page 1. Preparation of the shower and toilet chair for use 1.1 Transport........................2 1.2 Safety measures prior to use................... 2 1.3 Safe disposal of the packaging material..............2 1.4 Where to keep the instructions for use..............2 2. Product description 2.1 General information....................

  • Page 4: Preparation Of The Shower And Toilet Chair For Use

    1. Preparation of the toilet and shower chair for use 1.1 Transport On receiving the product, please check it for completeness, lack of faults and check it for any transport damage. Inspect the goods in the presence of your forwarder Should transport damage have occurred, please cause an inventory (determination of the faults) to be made in the presence of the forwarder.

  • Page 5: Product Description

    2.2 Application areas, use according to the intended purpose BORIS can be used as a toilet chair over the toilet or as a standalone device with a toilet bucket, or as a shower chair. Please observe the following guidelines: Over the toilet Open the toilet lid and the seat.

  • Page 6: Equipment For Basic Model

    2.4 Equipment for basic model • Anatomically-shaped seat pan made of PE, colour steel blue • Sub-frame made of stainless steel • Seat angle adjustment via gas pressure spring 200N • Mechanical height adjustment • 4 dual castors (100 mm) with locking devices 2.5 List of accessories •...

  • Page 7: Settings

    3. Settings 3.1 Seat angle adjustment You can infinitely adjust the seat pan from (-) 5° active to 30° passive. To do this, press the foot pedal (A) at the front right in travel direction on the base frame, so that the seat pan angle can be adjusted under slight pressure or tension.

  • Page 8: Seat Height Adjustment

    3.3 Seat height adjustment You can adjust the height of the seat pan in 2.5 cm steps. To do this, first loosen the two cap nuts (A) on the brackets between the pan and base frame on both sides. Now the height of the seat pan can be adjusted via the row of holes.

  • Page 9: Headrest

    4.2 Headrest The angle and height-adjustable headrest can be adapted to the respective patient. Height adjustment: To do this, loosen the screw (A) and adjust the height. Angle adjustment: To to this, loosen the screws (B) and the headrest can be adapted. 4.3 Footrest The footrest can be adjusted in terms of the knee angle, foot angle and height, and can simply be...

  • Page 10: Abduction Block With Integrated Spray Protection

    4.4 Table with padded armrest, pivotable In order to pivot the table, for example to make get- ting in and out easier, the pull catch (A) is pulled and the table can be pivoted away around the bracket on the left-hand side of the pan frame, or removed com- pletely.

  • Page 11: Pu Insertion Pad, Two-Part

    4.6 PU insertion pad, two-part For people sensitive to pressure, we offer a two-part insertion pad, which for example can easily be dis- mantled for cleaning purposes (with a mild detergent solution). To do this, the pad knobs (A) are removed from the holes in the seat pan, and the pad is removed.

  • Page 12: Spare Parts

    5.3 Spare parts Should you wish to order spare parts, please contact the specialist dealer who sup- plied you with the toilet and shower chair, stating the serial number (see Point 8.5). 5.4 Duration of use and re-use The expected duration of use of our product, dependent on the usage intensity and amount of re-use, totals up to "8"...

  • Page 13: Technical Data

    6. Technical data Dimensions - basic model Boris Boris Boris Boris Boris Size 0 Size 1 Size 2 Size 3 Size 4 Seat width at front 31 cm 36 cm 41 cm 46 cm 51 cm Seat width at rear 26 cm 31 cm...

  • Page 14: Guarantee

    7. Guarantee The two-year statutory guarantee period shall apply for all products. This guarantee period shall begin with the delivery or handover of the goods. Should a verifiable material or manufacturing fault occur within this time period, we shall, after carriage paid return to us, view the indicated damage and, if applicable, either repair or de- liver a new product at our discretion.

  • Page 15: Identification

    Fax: +49 (0) 54 05 / 909 - 109 declares on their sole responsibility that the product named below is classi- fied as product class 1 "BORIS" - the comfortable toilet and shower chair Art. No.: 52 00 100 (Size 0) 52 01 100 (Size 1)

  • Page 16: Serial Number / Date Of Manufacture

    · info@schuchmann-reha.de · Fon +49 (0) 5405 / 909 - 0 8.3 Product version The BORIS toilet and shower chair is available in five sizes and can be supplemen- ted through a diverse range of accessories (see Point 4).
