Seametrics AG2000 Instructions

Irrigation magmeter

Download this manual

The Leader in Flow Meter Value

I N S T R U C T I O N S

AG2000 Irrigation Magmeter

FEATURES

Rate and total indicator

Powder-coated diecast-aluminum electronics housing

Tamper-evident security seal

Cross-drilled screws (2) for tamper-evidence

Power/Output cable port access,

Tamper-sealed

Equalization lug

Welded steel epoxy-coated flow tube

316SS electrodes

Dual durometer rubber liner

Flanges, ANSI 150 lb. drilling

Need help?

Do you have a question about the AG2000 and is the answer not in the manual?

Page 1 The Leader in Flow Meter Value I N S T R U C T I O N S AG2000 Irrigation Magmeter FEATURES Rate and total indicator Powder-coated diecast-aluminum electronics housing Tamper-evident security seal Cross-drilled screws (2) for tamper-evidence Power/Output cable port access,...
Page 2 Possible Problem: Better Installation: Air bubbles and sediment on the Improved accuracy results from Fittings and Flanges. The AG2000 flanges have standard ANSI electrodes can affect accuracy. unimpeded electrodes. 150 lb. drilling, and should match up with any other ANSI 150 lb.
Page 3 Metal Pipe Installations. To equalize the electric potential WARNING: ELECTRICAL SHOCK HAZARD of the fluid, the meter, and the surrounding pipe, secure the When the AG2000 is installed in a plastic flange plates, factory-installed on equalization lug, to both piping system, or when externally powered, pipe flanges at one of the bolt holes.
Page 4 S e a M e tr i c s In c o r p o r a te d • 1 90 26 72nd Avenue Sout h • Kent, W ashington 98032 • USA ( P ) 2 5 3.8 72 .0 28 4 • (F ) 2 53 .872.0285 • 1. 800.975.8153 • ww w .seametrics.com...
