TTRobotix Super Hornet X650 Instruction Manual

457
285
463
365
SPECIFICATIONS / 規格表
X650
Product Name / 產品名稱
Frame type / 機架類型 Quad-copter
650mm
Diagonal distance / 對角線馬達軸距
2.47Kg(motor,esc,prop. Inc'd)
Frame weight / 機體重量
Motor stator size / 馬達定子尺寸 41x14mm
340rpm/V
Motor KV / 馬達KV值
30A
ESC current / 速控器電流值
ESC voltage / 速控器電壓值 6S Lipo(22.2V)
14"x4.7"
Propeller size / 槳尺寸
3.2Kg(6S/6000mAh)
Takeoff weight / 起飛重量
18mins(6000mAh)
Max hover time (est.) / 最大滯空時間(預估)
FEATURES / 特色
1. Enlarged frame plates provide abundant assembly space for electron systems
2. Safety protection and clean look design for the internal electron system
3. Compatible for major flight control systems & gimbals on the market
4. Foldable arms design is easy to pack and transport
5. Retractable landing skid with stable carbon fiber landing poles
6. Under mounted battery plate system with better center of gravity and stable flight
7. Pre-painted body with sleek scheme
thundertiger.com
650
1. 加大機架提供充足的電子系統配置空間
2. 兼具安全保護和簡潔美觀的內藏式電子配置方式
3. 可搭載所有主流飛控系統與雲台機構
4. 可收折機臂設計方便收納與攜帶
5. 高強度碳纖腳架並內建自動收腳功能
6. 下置式電池板可有效調節機體重心,提升飛行穩定度
7. 原廠塗裝機殼
JK6195
INSTRUCTION MANUAL INSTRUCTION MANUAL
組 裝 說 明 書
No.4000
This product is not a toy. Before you assemble and use this product, please read this
manual thoroughly.
This product and its contents may different from the graphics shown on this manual
and are subject to change without prior notice due to product improvements and
specification changes.
本產品非一般玩具，組裝與操作前請詳閱本產品說明書。
本產品及所附零件可能跟圖示有所差異。因產品後續之設計研發或功能不斷改善之原因，我們
將保留產品規格變更權利，不再另行通知使用者。
More information can view the tutorial videos on our TTR web page (www.ttrobotix.com)
or YouTube channel (https://www.youtube.com/user/ThunderTigerVideo)
您可登入TTR官網或YouTube官方頻道，以獲取最新的產品資訊與更詳盡的產品說明
