Automist

Fixed Wall

Head Handbook

Version 1.2.3

The Automist Fixed Wall Head Handbook is designed to

provide Accredited Automist Installers with essential

information

regarding

specification,

installation,

maintenance and commissioning of the Automist fire

protection device.

Supersedes – Automist Fixed Wall Head Handbook Version 1.2.2

Table of Contents

Need help?

Do you have a question about the Automist and is the answer not in the manual?

Questions and answers

Summary of Contents for Plumis Automist

Page 1 Automist Fixed Wall ® Head Handbook Version 1.2.3 The Automist Fixed Wall Head Handbook is designed to provide Accredited Automist Installers with essential information regarding specification, installation, maintenance and commissioning of the Automist fire protection device. Supersedes – Automist Fixed Wall Head Handbook Version 1.2.2...
Page 2: Table Of Contents
Fire Performance and Regulations Compliance ......................8 LABC Registered Detail ............................8 Fire Engineered Applications ..........................8 Quality Assurance ................................. 9 HOW TO SPECIFY THE FIXED HEAD AUTOMIST SYSTEM ..................10 Specifying Automist ..............................11 Room Compatibility ............................... 13 Spray Head Placement ............................14 Detection System ................................
Page 4: Introduction To The Fixed Wall Head System
® Automist ® Fixed Wall Head Handbook v1.2.3 S M A R T S C A N INTRODUCTION TO THE FIXED WALL HEAD SYSTEM Plumis Ltd Copyright © 2017. All Rights Reserved. Page 4 of 41...
Page 5: Introduction
When this product has reached the end of its serviceable life, it should be disposed of in a safe • manner. IMPORTANT: Once installed, complete and submit an installation and commissioning form to Plumis. WARNING: To avoid hazards, all installation procedures and maintenance must be supervised by an Accredited Automist Installer.
Page 6: Automist Operation
S M A R T S C A N Automist operation In the event of a fire, Automist is triggered automatically by a relay contact, provided by one or more heat alarms/detectors, compliant with either BS 5446-2 or BS EN 54-5...
Page 7: The Automist System
Fixed Wall Head Handbook v1.2.3 S M A R T S C A N The Automist System WRAS approved isolation valve Automist Smartscan supply label & cable tie ¾” single check valve Filter ¾” Stainless Steel Inlet Hose Automist Smartscan Pump Unit...
Page 8: Fire Performance And Regulations Compliance
A copy of the report can be downloaded from the Plumis website. Fire Engineered Applications Automist may be used in a variety of applications as part of a fire engineered solution where suppression is used as a key enabler for means of escape by extending tenable conditions.
Page 9: Quality Assurance
Water Byelaws (Certificate number 1102330) Company • Third Party Certification by BRE Global have established Plumis Limited have complied with the Quality Management Systems requirements of ISO 9001:2008 for the design, manufacture and supply of water mist fire suppression systems.
Page 10: How To Specify The Fixed Head Automist System
® Automist ® Fixed Wall Head Handbook v1.2.3 S M A R T S C A N HOW TO SPECIFY THE FIXED HEAD AUTOMIST SYSTEM Plumis Ltd Copyright © 2017. All Rights Reserved. Page 10 of 41...
Page 11: Specifying Automist
S M A R T S C A N Specifying Automist Automist design specification guidelines state that a single pump can cover an area of up to 32m , with a maximum ceiling height of 3.5m. Based on third party test data, spray heads must be located within 5m line of sight of any possible fire location.
Page 12 Building Control or other involved third parties. Automist is accepted for use as a compensatory measure for loft conversions where an open plan ground floor layout exists. The applicable regulatory guidance is given in paragraph 2.20.b of Approved Document B (Fire safety) –...
Page 13: Room Compatibility
Room Compatibility A single Automist pump unit was tested by Exova Warrington in an area of up to 32 square metres (2.5m ceiling height) with fire hazards up to 5m away. The spray head should therefore be within 5m of & in the approximate line of sight of any fire hazards.
Page 14: Spray Head Placement
• Spray Head Placement The Automist Head is designed to be affixed to a standard 50mm deep single-gang mounting box (85mm x 85mm with fixing centres offset centre to centre by 60mm). IMPORTANT: The Automist head must be located where the spray pattern will not be obstructed and 750mm clearance is provided adjacent to each of the active nozzles.
Page 15: Detection System
DO NOT trigger Automist from a smoke alarm as this will lead to unwanted activations. • DO NOT connect the Automist pump’s alarm input to any device other than a volt free relay. In • particular, connecting the three coloured cables to the alarm interconnect or to any power supply whatsoever is likely to damage the Automist pump beyond repair.
Page 16 BS5839-1:2013 section 22.3. Notably this implies a working range of no more than 5.3m for heat alarms and gives guidance on unusual ceiling types. Automist’s use of heat alarms does not affect or reduce any requirements for the use of smoke •...
Page 18 Stud extender or nut wrench • A commissioning kit (gauge, nozzle tool) • PTFE plumber’s tape • A single gang wall mounting electrical box suitable for your wall type • Plumis Ltd Copyright © 2017. All Rights Reserved. Page 18 of 41...
Page 19: A) Preparing The Site
The circuit supplying a single Automist unit would commonly be protected by a type ‘C10’ or ‘C16’, for example, or ‘C20’ / ‘C32’ for two Automist units. This should be on a C-type breaker, on an RCBO or a RCD protected circuit.
Page 20: B) Configuring The Spray Head
Automist system. Many options for such an alarm are available and Plumis recommends the purchase of an inexpensive alarm from Amazon, using the following link: https://www.amazon.co.uk/gp/product/B01GE3NDB4/ref=pd_cp_107_1?ie=UTF8&psc=1&refRID=REA5Y9F0R...
Page 21: C) Installing The Automist Head
The manifold is set up with 2 x A16 nozzles and 2 blanks. C) Installing the Automist Head IMPORTANT: When installing an Automist head with four nozzles you must make sure the active nozzles are pointing into the room and not towards the wall. PTFE tape should be wrapped approximately three times around the hosetail thread that enters the spray head.
Page 22 IMPORTANT: Make sure the hose is slack enough to allow easy removal of the head for commissioning. This may require use of a conduit in some wall types. Plumis Ltd Copyright © 2017. All Rights Reserved. Page 22 of 41...
Page 23: D) Connecting The Water Supply
Automist pumps and the normal domestic supply in its worst condition. Otherwise a priority valve or a booster pump may need to be used to provide the required flow and pressure. It is responsibility of the installer to ensure the water supply to the Automist pumps is adequate.
Page 24 IMPORTANT: If new pipe has been fitted remember to flush out any contaminants before connecting to Automist, to avoid clogging the nozzles. Connect the high pressure hose from the assembled head to the outlet on the pump. Plumis supplies suitable high-pressure hoses. If using another brand of hose, follow Plumis’s guidance note, available on the Plumis Partner Site.
Page 25 IMPORTANT! To comply with water regulations, an approved isolation valve must be used when connecting the check valve to the mains. A cable tie is provided to tie the Automist supply pipe label to the isolation valve. The warning label must be visible but must not obstruct isolation valve operation.
Page 26: D) Connecting The Electrics
Using a conventional wrench, apply another 1/2 turn clockwise to guarantee a reliable seal. D) Connecting the electrics IMPORTANT! The Automist pump should be positioned in a safe and dry location where it is easily accessible, the button will not be pushed accidentally, and the front panel remains visible when the access door is open.
Page 27 STOP button is inaccessible. Where required, the loop should be cut and each end of the wire connected via FP200 cable to a momentary action, normally closed, push button switch (see diagram below). Plumis Ltd Copyright © 2017. All Rights Reserved. Page 27 of 41...
Page 28 S M A R T S C A N The button should have an appropriate IP rating (e.g. IPX5 if used in the room protected by Automist), located as close to the pump as possible and should be clearly labelled. The auxiliary button cannot be used to commission the unit but can be used to enter ALARM TEST MODE (see page 30).
Page 29: E) Commissioning And Maintenance
Commissioning must be performed by an Accredited Automist Installer yearly. When Automist is powered up for the first time the yellow FAULT LED will indicate that the system has not been commissioned. Commissioning is a simple programmed procedure which allows Automist to be tested.
Page 30: The Automist Controls
The Automist Controls STOP Button: Pressing the STOP button during a fire condition will stop the Automist pump for 2 minutes. If at the end of 2 minutes, an alarm input remains active, Automist will recommence mist operation. If the alarm condition has ended, Automist will return to stand-by.
Page 31 By leaving an installed system with pressures outside the specified range, you might become liable for deaths or injuries. If the achieved output pressure is outside the specified range, refer to the commissioning troubleshooting guide (see page6) and contact Plumis on 020 7871 3899 if the situation cannot be resolved.
Page 32 Carefully remove the test hose and gauge and re-attach the cap on the test point adapter. Following a successful pressure test, the high pressure hose must be cleared of water by connecting a suitable pump to the Plumis supplied attachment, that is connected to the test point tee.
Page 33: Power Supply
Automist should be supplied using FP200 cable or better, ideally inside conduit or protected 50mm deep within a wall • Automist may be protected by an RCD or RCBO but this protection must not be shared with other circuits. Therefore Automist should be connected to the non-protected side of the consumer unit. •...
Page 34: Alarm Relay Placement
The Installer Commissioning form should have been provided (can be obtained from Plumis or the installer) with a matching layout drawing The Plumis Warranty Certificate is provided (can be obtained from Plumis) once the layout has been submitted and approved by Plumis.
Page 36: Cleaning
CAUTION! Do not attempt to repair the Automist wall head or pump unit. Doing so will invalidate your warranty. Automist should be serviced or replaced if it has been if any part of the system, including any heat alarms, have been exposed to fire conditions.
Page 37 STOP on the pump. If Automist is not triggered, power off the system and replace the relay with a two-way a.c. light switch. The NO and NC terminals on the switch will normally be labelled L1 and L2 (both L1 and L2 terminals must be present and connected).
Page 38: Fixed Head System Servicing
Disconnect the inlet hose and check for blockages on the pump strainer and within the hose. Pump damaged in Disconnect the high pressure hose from the Automist head transit and re-run the commissioning procedure with the high pressure hose outlet placed inside a container with volume markings.
Page 39: Warranty
If the product is found to have failed for reasons outside our warranty cover Plumis may quote to repair the unit and return it. Where products are replaced or repaired under warranty, they will be returned to a UK address free of charge.
Page 41: Plumis Ltd Copyright © 2017. All Rights Reserved
Insert the nozzles and commission the system 10. Check the pressure/ Record the new pressure (75-100 bar) 11. Check for leaks. Plumis Ltd Copyright © 2017. All Rights Reserved. Page 41 of 41...
