Summary of Contents for AUDIO MASTER A200
- Page 1 AUDIO MASTER A SERIES 2 CHANNELS POWER AMPLIFIER USER’S MANUAL TWO CHANNELS POWER AMPLIFIER PROFESSIONAL POWER AMPLIFIER CLASS AB / CLASS H CLASS AB / CLASS H...
- Page 2 CATALOGUE MALFUNCTION ELIMINATION TWO CHANNELS POWER AMPLIFIER No response CATALOG TWO CHANNEL POWER AMPLIFIER Make sure that the AC cord is completely inserted in the socket with electricity. Try to use other equipment to test the AC power, like the lamp. Check Important precautions and application range whether the power switch at the front panel is on or not.
- Page 3 Foreword SPECIFICATION TWO CHANNELS POWER AMPLIFIER TWO CHANNELS POWER AMPLIFIER WELCOME Model A1000 A1200 A1400 Thank you very much for purchasing our products. 8 ohm stereo power** 1000Wx2 1200Wx2 1400Wx2 The two channels professional power amplifier made 4 ohm stereo power** 1500Wx2 1800Wx2 2100Wx2...
- Page 4 FRONT PANEL FUNCTION INTRODUCTION TWO CHANNELS POWER AMPLIFIER SPECIFICATION TWO CHANNELS POWER AMPLIFIER FUNCTION INTRODUCTION OF FRONT PANEL Model A200 A400 A600 A800 Thermal-The protected overheat 8 ohm stereo power** 250Wx2 400Wx2 600Wx2 800Wx2 overload,short circuit,dc,softstart Handle Ready-Indicator 4 ohm stereo power**...
- Page 5 SYSTEM CONNECTION CASE 3 TWO CHANNELS POWER AMPLIFIER FRONT PANEL FUNCTION INTRODUCTION TWO CHANNELS POWER AMPLIFIER SYSTEM CONNECTION FUNCTION INTRODUCTION OF FRONT PANEL(3U) INTRODUCTION Thermal-The protected overheat Stereo mode overload,short circuit,dc,softstart move mode switch to Handle Ready-Indicator stereo position ON-open situation Power switch SIG-signal indication STEREO...
- Page 6 SYSTEM CONNECTION CASE 1 TWO CHANNELS POWER AMPLIFIER SYSTEM CONNECTION CASE 2 TWO CHANNELS POWER AMPLIFIER Input connection 8ohm Speaker connection at bridge or parallel output SPEAKON caron socket or terminal Connection mode:+1+2. XLR mixer Balanced connection Wiring Feet 2 to positive pole Feet 3 to negative pole Feet 1 to grounding pole Unbalanced connection...
