Summary of Contents for Ronds RH560-4G
- Page 1 Wireless Machinery Monitoring Station RH560-4G User Manual Anhui Ronds Science & Technology Incorporated Company 2016.03 第 1 页 共 17 页...
-
Page 2: Table Of Contents
Content 1. Preface.............................3 1.1 Welcome........................3 1.2 Statement........................3 2. Product introduction....................... 3 2.1 Summarize........................3 2.2 General structure of system..................4 2.3 System operating procedure..................4 2.4 Product features and outlooking................5 2.5 Technical specifications....................5 3. Security introduction.......................7 3.1 Summarize........................7 3.2 Operating regulations....................7 4. -
Page 3: Preface
1. Preface 1.1 Welcome Welcome to use RONDS products. Before any operating, please read this manual carefully and keep it appropriately in case of any query. 1.2 Statement When you read this manual, please pay attention at the following marked content, and make sure the equipment will be used properly. -
Page 4: General Structure Of System
2.2 General structure of system 2.3 System operating procedure 1) In MOS3000 software of the server, configure relative organization, machine, measuring points, and data collection, alarm strategy, then send DAQ parameter. MOS3000 support for multiple DAQ parameter sending. 2) Wireless collection station will update the DAQ parameter after receiving from MOS3000 software. -
Page 5: Product Features And Outlooking
2.4 Product features and outlooking Entirely wireless condition monitoring system, no cable laying, make the installation procedures be never so easy. communication type 3G/4G, realize monitoring of both constant and variable speed rotating machines. Low consumption design, IP66 protection degree. ... - Page 6 RH560 Wireless data collector Input and output 2.4GHz IEEE 802.15.4 Communication with Sensor Indicator LED Total 3 pieces (working, communication, abnormal status) 60 unit Maximum Number of RH505 Electrical and Structure Parameter Power Supply 120V AC 203 mm × 82 mm × 260 mm (Length * Width * Dimension Height) 3 kg...
-
Page 7: Security Introduction
People without professional training is not allowed to disassemble and repair this equipment, RONDS is not responsible for the accidents that caused by this kind of operating. Correctly configure parameter with products and connect power supply. ... -
Page 8: Installation Announcements
Please follow the security regulations strictly when installation, operate everything carefully in case of any equipment damage or human injury. 【 Notice 】 ： This equipment should be installed by RONDS application engineers or other people with professional training. 【Danger】 ：Please make sure the security when using 220V power supply in case of any human injury. -
Page 9: Rh505 Installation
Antenna installation： Install the HG‐2404U gray antenna in RF port, connection type is N. the 3G/4G antenna should be installed in4G port. System connection： The 120V power supply is go through the PWR port from RH560 bottom, and fixed with PG screw. -
Page 10: Announcement For The First Time Using
hose clamp for triggering, the hose clamp is installed on the rotating shaft. 【Notice】 ：After installation, the distance between sensor front and hose clamp is 8‐10mm. 【Warning】 ：The machine should be stopped during installation. 4.5 Announcement for the first time using When received new equipment, please try to connect with software MOS3000, make sure the performance is good before installing on machine. -
Page 11: Rh505 Switch And Led Description
Power on Power off Quick Flicker(0.2s each ) Abnormal communication with server Slow Flicker (1S) Normal communication with server Flicker Network disconnected 【Notice】 ：Under 3G/4G communication, RH560 will disconnect with server automatically after data uploaded, now the flicker of COM is normal phenomenon, it doesn’t mean there is network problem. -
Page 12: Rh509 Switch And Led Description
5.6 RH509 Switch and LED description Open the black cover of RH509, there is a switch ON and switch OFF option. Switch on RH560 and RH509, the LED of RH509 will show as: light for 3 seconds‐>flicker once‐>off，this means RH509 is working normally, there is other status of the LED: Indica Status Description... -
Page 13: User Login
6.2 User login Double click the “MOS3000 online monitoring system” icon on desktop appears the following window, input the server name (such as 192.168.1.153 ） , User name （ Default as ”Admin”）, password is blank, then click “login”. 【Notice】：Make sure MOS3000 System configuration tool and Online service is started before login, there should be a “tick”... - Page 14 2) Click “Online management”, create “collection station” Collection station type: RH560 Server name: choose the right database to store data; or create new database in the popup windows Collection station code: input the last four number Collection method: variable speed or constant speed, test mode is forbidden. Monitoring machine: click it to add relative machines Associate measuring point Page 14/17...
-
Page 15: Data Diagnosis And Analysis
Time waveform: time interval to collect normal time waveform Sampling value: time interval to collect RMS value Long time waveform: the longest wave can reach to 2M Speed strategy: associate speed measuring point in speed channel 3). This system support for multiple DAQ definition sending. 6.4 Data diagnosis and analysis Data viewing and analysis can be done in the software, for detailed information please refer to 《MOS3000 Online monitoring software user manual》. -
Page 16: Product Maintenance And Fault Elimination
7.2 Fault analysis and elimination When there is problem with the equipment, please check it according to the following table, if the problem still can’t be solved, please contact technical department of RONDS company. Fault type Possible reason... - Page 17 FCC Information and Copyright This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
