B&G Mini DB Instruction Manual

Safety Precautions

• Gasoline. The on y fuel for this fogger is 87 octane gasoline.
Do not mix oil with the fuel. Do not add fuel to the fuel tank
when the engine is running.
• Insecticide formulation. Formulations used must be mixed
according to product label directions.
• Safety equipment. Follow insecticide label directions that
require operator to use personal safety equipment.
• Improper use. Do not leave the fogger unattended when
motor is operating, or when nozzles are operating. Do not
operate the fogger indoors without proper ventilation.
• Public safety. People, including children playing, should not
be in a treatment area.

Before Starting

• Be certain that oil has been added to the engine. Some
oil may be visible when the cap is removed, but the
bottle of oil supplied with the fogger must be added
before starting.
• Turn the flow valve to the Off position (horizontal) before

starting the engine.

• Turn the throttle to the idle position, completely to the right.
• Turn the flow valve to the Off position (horizontal) before
starting the engine.
Starting the Engine
1. Motor switch turned On
2. Move Choke Lever up
3. Press / release the Primer Bulb until gas is visible in the bulb
4. When gas is in the Primer Bulb, press bulb 2 times to
deliver gas to carburetor
5. Pull start cord 1 or 2 times until there is resistance, then
pull quickly to start the engine
6. Move the Choke Lever down when the engine is running
smoothly
Mini DB Fogger
INSTRUCTION MANUAL
Fogging Start/Stop Sequence
• Nozzle Adjustment: The flow of formulation to the nozzle
is regulated by a control valve. Before starting the engine,
turn the control valve to the Off position (horizontal).
• Start Fogging: Turn On (vertical position) the control valve
on the formulation line to the nozzle.
• Control valve: When fogging application is complete: 1st
move throttle to idel position; 2nd turn off the engine, 3rd
turn control valve to the Off position.

Operation

• Fill formulation tank with insecticide. It is best to start
with a full tank. It will hold 32 ounces.
• Fill fuel tank with fresh gasoline.
• Move throttle to idle position (completely to the right).
• Start engine and allow it to run 30 seconds before
adjusting the throttle and turning On the control valve to
begin fogging.
• Formulation tank flush. A professional flushing solution
must be used to get complete cleaning. Empty formulation
tank and add about 8 ounces of flushing solution. Fog until
the formulation tank is empty and fogging stops.
39974 Rev 3/17
