- Page 1 Blade Hand Dryer Instructions Manual...
-
Page 2: Table Of Contents
Table of Contents Product Dimensions Names of the Various Components Product Features, Technical Specifications & Package Contents Installation Instructions Installation & Safety Guidelines Operation Guidelines Cleaning & Maintenance Guidelines Warranty Details... -
Page 3: Product Dimensions
Product Dimensions 230mm 300mm 115mm 95mm 138mm 278mm... -
Page 4: Names Of The Various Components
Names of the Various Components... -
Page 5: Product Features, Technical Specifications & Package Contents
Product Features, Technical Specifications & Package Contents Product Features: • The contemporary, ergonomic style gives the Blade its streamlined look • A heavy-duty Stainless Steel casing offers excellent protection from corrosion and vandalism • The automatic ‘no touch’ operation makes this a hygienic system •... -
Page 6: Installation Instructions
Installation Instructions Blade Hand Dr Installation Instructions Drill the fixing points: • Offer the installation panel up to the mounting surface and mark the five fixing points through the holes in the backplate. Drill the five marked fixing holes and insert the supplied wall plugs. Offer the installation panel up to the wall, and insert the five fixing screws through the panel into the wall plugs. - Page 7 Blade Hand Dryer Blade Hand Dryer structions Instructions Blade Hand Dryer Blade Hand Dryer up to the the five les in the ked fixing d wall plugs. plugs. up to the g screws wall plugs. ugs. down 5mm down...
-
Page 8: Installation & Safety Guidelines
Installation & Safety Guidelines • All electrical installation and repair work should be carried out by a qualified electrician in accordance with current locals codes or regulations. • Do not attempt any disassembly or modification of the unit that is not expressly stated in this manual. -
Page 9: Operation Guidelines
Operation Guidelines Before inserting hands under the dryer, shake off any excess water. This hand dryer incorporates no touch sensor activation for hygienic use. Simply place your hands within the air outlet compartment and the hand dryer will be automatically activated. Remove your hands away from the air outlet and the hand dryer will be deactivated after 2 seconds. -
Page 10: Cleaning & Maintenance Guidelines
Cleaning & Maintenance Guidelines Cleaning and maintenance should be carried out by service personnel only, after ensuring that the unit is disconnected from the power supply. It is recommended that cleaning be carried out regularly every week. A) Cleaning the unit body Simply wipe down the exterior of the dryer with a damp cloth, removing any build of up dirt, paying particular attention to the sensor. -
Page 11: Warranty Details
Warranty Details • All Tekflo Hand Dryers are guaranteed to be free from defects in parts and manufacture for 2 years from the date of purchase, provided that the product is used under the normal operating conditions stated within the manual. - Page 12 Visit www.tekflo.com or email enquiries@tekflo.com for more information...
