Page 2: Table Of Contents
ontents Read this manual Inside you will find many helpful hints on how to use and maintain your washer properly. Just a li�le preventive care on your part can save you a great deal of time and money over the life of your washer. You will find many answers to common problems in the Troubleshooting section. - Page 3 mportant Safety Information READ ALL INSTRUCTIONS BEFORE USE. For your safety, the information in this manual must be followed WARNING! to minimize the risk of fire or explosion, electric shock, or to prevent property damage, personal injury, or loss of life. IMPORTANT SAFETY INSTRUCTIONS WARNING : To reduce the risk of fire, electric shock, or injury to persons when using the washer,...
- Page 4 dentification of Parts HOT WATER SUPPLY HOSE DETERGENT BOX COLD WATER SUPPLY HOSE Make sure the water SOFTENER DISPENSER does not leak. POWER PLUG If the supply cord is damaged, BLEACH INLET it must be replaced by the manufacturer or its service agents or similarly qualified person in order to avoid a hazard.
-
Page 5: How To Remove Stains
How to Remove Stains Pretreating dirt and stains Brush a little washing detergent dissolved in water onto stains, collars, and cuffs to help shift dirt. The secret of stain treatment is immediate action. When an accident happens, plunge the stained area into cold water and sponge it down. This prevents the stain from setting. -
Page 6: Preparation Before Washing
, a net will prevent Doing so can result in death, explosion, or fire. tangling during washing. Fasten zippers, hook, and strings to make sure that these items don't snag on other clothes. Nylon net is not supplied by LG. -
Page 7: Water Level And Temperature
ater Level and Temperature Water Level • This machine detects the quantity of laundry automatically, then sets the water level and proper amount of detergent. • When you select a wash program, the water level and amount of detergent (to be used) will be shown on the control panel. -
Page 8: Use Of Detergent
se of Detergent Choosing the Right Detergent • We recommend powdered detergent for the detergent box. • Soap or granulated soap powders should not be used in your washing machine to prevent build-up. • When washing woolens, remember to use a detergent suitable for washing woolens. Amount of Detergent •... - Page 9 se of Softener and Bleach Using Fabric Softener • Dilute fabric softener with water. Undiluted fabric softener may result in spots that look like Softener dispenser ( oil stains. • Measure and add the recommended amount of fabric softener into the compartment marked with this symbol( ��...
- Page 10 unction of Each Button Fully automatic control The Normal program is used for average The water level lights will scroll up and down while day-to-day washing. the washer is determining the optimum water level Press the POWER button to turn power on. for your load.
- Page 11 Manual control Other programs are selected as follows: Press the POWER button to turn power on. Load clothes. Add detergent, bleach, and softener as desired in the appropriate dispensers. Select water temperature, water level, program, and wash options as described below. Close the lid and press the START/PAUSE button.
-
Page 12: Normal Wash
ashing Programs Press the POWER bu�on to turn the power on. Press the PROGRAM bu�on to select the washing program. Normal Wash Use this program for normal clothes except woolens and lingerie. Delicate Wash Delicate clothes (lingerie etc.) which may be easily damaged can be washed. Economy Wash 1 ⁄... -
Page 13: Favorite Wash
avorite Wash Pressing the Favorite button allows you to store your Favorite wash conditions in the normal cycle memory and then recall it for use at a later time. To save your Favorite cycle Press thePOWER bu�on to turn power on. Press the PROGRAM bu�on to select the Favorite program. -
Page 14: Ecosave Wash
cosave Wash Ecosave is the economical program to minimize water consumption. Press the POWER bu�on to turn power on. Press the PROGRAM bu�on to select the Ecosave program. Press the START/PAUSE bu�on. • Left time is displayed. Close the lid. •... -
Page 15: Soak Wash
oak Wash Use this mode to wash normal clothes or thick and heavy clothes which are excessively dirty. Soak mode can be used with Normal or Jean or Silent or Favorite program. Press the POWER bu�on to turn power on. Press the PROGRAM bu�on to select the washing program. -
Page 16: Delay Start Wash
elay Start Wash Delay Start wash is used to delay the finishing time of the operation. The hours to be delayed can be set by the user accordingly. The time on the display is the finishing time, not the start time. Press thePOWER bu�on to turn power on. -
Page 17: Washing Option
ashing Option When you only need the Wash, Wash/Rinse or Rinse cycles, these can be set manually. When you only need the Wash, Wash/Rinse or Rinse cycles, these can be set manually. Press thePOWER bu�on to turn power on. Press the WASH/RINSE/SPIN bu�on to select the desired option. (Refer to p. -
Page 18: Other Useful Functions
ther Useful Functions Child Lock Function If you want to lock all the keys to prevent settings from being changed by a child, you can use the child lock option. How to Lock Press the POWER bu�on. Turn Power on. Press the START/PAUSE bu�on to start washing. -
Page 19: Placing And Leveling
lacing and Leveling Please ensure that transit restraint has been removed before operating your machine. Place the machine on a flat and firm surface which allows proper clearance. Concreate flooring is best. Washer should not be installed on rugs or exposed to the weather. more than 10cm We suggest a minimum clearance of 1”... -
Page 20: Connecting Hoses
onnecting Hoses Water Supply Hose Connect the water supply hose to the tap. Push the water supply hose up so that the sealing Water washer within the hose can adhere completely to Sealing Washer the tap. Tighten it by turning to the right. Water Supply Hose Connect water supply hose to the machine. -
Page 21: Grounding Instructions
rounding Instructions Grounding Instructions With Ground Insert Space Terminal If the AC current outlet has no ground terminal, separate grounding is required. Note that AC power outlet configurations may differ from country to country. If your outlet has no ground terminal or does not match your plug on the washer, consult a qualified electrician. - Page 22 ser Maintenance Instructions When you have finished washing • Turn off taps to prevent the chance from flooding. • Always unplug the power cord when not in use. Inner-Tub Leave the lid open after washing to allow moisture to evaporate. If you want to clean the inner-tub, use a clean soft cloth dampened with liquid detergent, then rinse.
- Page 23 Note • If the lint filter is worn out or damaged, contact an LG Service Center for new one. • The amount of collected lint depends on the load size and type. Clean the lint filters as necessary.
- Page 24 roubleshooting Look for your problem below, then check the things we suggest. More often than not, this will give you the answer to your problem, and you’ll be able to carry on without having to telephone your service center. WASH PROBLEM Problem Possible Causes What To Do...
- Page 25 roubleshooting WASH PROBLEM Problem Possible Causes What To Do The laundry Water temperature • Use warmer water temperature. isn’t clean is too cold. Water temperature • Select the wash temperature according to soil type. is not correct. For example, blood and mud are better in cold water, while oily soils are better in warmer water.
- Page 26 Check if electric power has gone off. Is the laundry evenly balanced? Spin Failure Is the washing machine placed on a flat surface? Door(Lid) Open Is the lid closed? Ask for help at the Service Center. Internal sensing Call (888)542-2623[LG-CANADA] failure Power failure Overflow failure...
- Page 27 Model WF-5443TPP WF-7979TTP Size 525(W)x530(D)x850(H) 540(W)x540(D)x850(H) Water tab pressure 30 - 800 kPa (0.3 - 8 kgf /cm In our continuing effort to improve the quality of our appliances, it may be necessary to make changes to the appliance without revising this manual.
