UNIVERSAL SMOKE SENSING TECHNOLOGY
10 YEAR PERMANENT POWER SEALED BATTERY
THANK YOU for purchasing this smoke and fire alarm. This alarm
does not require battery changes. The tamper proof permanent power
sealed battery which will last for approximately 10 years. This manual in-
cludes important information regarding where to install the alarm,
how to operate, maintenance, testing and product features. It also in-
cludes tips and information which can help protect you and your family.
Smoke Alarm Limitations and Functions ................................. 2
Recommended Location of Alarms.......................................... 3
Avoid These Locations ............................................................ 4
Early Warning .......................................................................... 4
How to Install ........................................................................... 4
Locking/AlarmTamper Feature ................................................. 4
Operation, Testing & Maintenance .......................................... 5
QUICK FIND
Silence Feature ....................................................................... 6
Cautions/Warnings .................................................................. 6
Battery and Alarm Deactivation ............................................... 6
Develop and Practice a Plan of Escape .................................. 7
Quick Reference Guide / Operational Summary ..................... 8
Warranty ..................................................................Back Cover
This smoke alarm uses an extremely small amount of a radioactive
element in the ionization chamber. Do not tamper with radioactive sealed
source or try to repair the smoke alarm yourself.
MODEL MI3050S
2-in-1 SMOKE & FIRE ALARM WITH
READ ALL INSTRUCTIONS
Table of Contents:
Alarm Originating Feature & Reset................... 5
®
READ ALL INSTRUCTIONS
Conforms to
UL Std. 217
Single Station Smoke Alarm
Page #
Advertisement
Table of Contents
Related Manuals for Universal MI3050S
Summary of Contents for Universal MI3050S
-
Page 1: Table Of Contents
Conforms to UL Std. 217 MODEL MI3050S Single Station Smoke Alarm UNIVERSAL SMOKE SENSING TECHNOLOGY 2-in-1 SMOKE & FIRE ALARM WITH 10 YEAR PERMANENT POWER SEALED BATTERY READ ALL INSTRUCTIONS THANK YOU for purchasing this smoke and fire alarm. This alarm does not require battery changes. -
Page 2: Smoke Alarm Limitations And Functions
Photoelectric. Universal Smoke Sensing Technology® is an ionization alarm containing patented Smart Alarm Technology. Alarms containing Universal Smoke Sensing Technology are effective at detecting fast flaming fires and slow smoldering fires. Ionization smoke alarms are typically more effective at detecting fast flaming fires—fires which consume combustible materials rapidly and spread quickly. -
Page 3: Recommended Location Of Alarms
RECOMMENDED LOCATION OF ALARMS • Locate the first smoke alarm in the immediate area of the bedrooms. Try to protect the escape route as the bedrooms are usually farthest from an exit. If more than one sleeping area exists, locate additional smoke alarms in each sleeping area. If a hall is more than 40 feet (12 meters) long, install a smoke alarm at each end. -
Page 4: Avoid These Locations
AVOID THESE LOCATIONS • the garage – products of combustion are produced when you start your vehicle. • near appliances or areas where normal combustion regularly occurs (kitchens, near furnaces, gas hot water heaters). Use smoke alarms with U.S.S.T. ® or photoelectric sensors, or smoke alarms with Silence Feature for these areas. -
Page 5: Operation, Testing & Maintenance
Detach the breakaway alarm locking pin from the mounting bracket. FIGURE 1 Insert the pin into the hole in the side of the alarm after the alarm has been installed on the mounting plate. Refer to the diagram below for correct placement. INSERT ALARM LOCKING PIN HERE (optional) -
Page 6: Battery And Alarm Deactivation
IMPORTANT CONSIDERATIONS YOUR ALARM HAS BEEN DESIGNED WITH A PRODUCT END-OF-SERVICE LIFE WARNING WHICH WILL SOUND AFTER APPROXIMATELY 10 YEARS OF OPERATION FROM INITIAL POWER UP. NOTE: MANUFACTURER RECOMMENDS REPLACEMENT OF THIS ALARM 10 YEARS AFTER DATE OF INSTALLATION. NOTE: NUMEROUS ALARMS OR PROLONGED ALARMING IS NOT TYPICAL AND WILL CONSUME THE BATTERY CAPACITY, SHORTENING THE LIFE OF THIS PRODUCT. - Page 7 Deactivation of the alarm is permanent. Do not attempt to open the alarm for any reason. Place this alarm into shut-down mode at the end of its useful service life. Once the smoke alarm has entered end-of-service-life mode, it is necessary to deactivate the alarm operation. This will stop the product end-of-service-life warning signal and also discharge the remaining capacity of the battery to render it safe for disposal.
-
Page 8: Develop And Practice A Plan Of Escape
REPAIRS AND SERVICES This smoke alarms contains less than 1 microcurie (37 kilobecquerel) of Americium 241, a radioactive material. The distribution of these ionization-type smoke alarms is licensed by the U.S. Nuclear Regulatory Commission; the consumer is exempt from any licensing or requirements. -
Page 9: Quick Reference Guide / Operational Summary
QUICK REFERENCE GUIDE / OPERATIONAL SUMMARY ALARM AUDIBLE & VISUAL SIGNALS CONDITION RECOMMENDATION HORN RED LED New - Out Silent To activate the alarm, remove the pull tab. The alarm will sound one long beep to confirm it is powered up. Press the Test/Silence of Package button. -
Page 10: Warranty
MODEL MI3050S TEN-YEAR LIMITED WARRANTY USI Electric, Inc. /Universal Security Instruments, Inc. (“USI”) warrants this product to be free from defects in material and workmanship for a period of 10 (ten) years from the date of purchase. This warranty shall not apply to any damage which may be caused by the sealed batteries used in this product.
