Male XLR Output - The XLR chassis plug provided will mate with any standard microphone cable
wired for 'balanced' signals. The signal is high quality equal to that of a balanced line, but is an un-
ballanced signal. It is identical to to that appearing on the JACK output, tip connection.
XLR Output Pin Connections -
PIN 1- Ground
The signal appearing in PIN 2 is IN PHASE with the signal appearing on the TIP contact of the JACK
output.
Note to our American customers:
The AP10 Acoustic PreAmp is known as the GG10 in Europe. In the interests of conservancy, please
transpose all references to GG10 to AP10. The products are otherwise totally identical and is exactly
the same as the AP10 formerly available under the MORLEY brand except for the male XLR ouput
connector.
Thanks for your assistance in saving materials and costs.
Stewart Ward
AP10/GG10/JD10 Designer.
Distributed in USA By:
Atomic Guitars, Little Rock, AR72205 - www.atomicguitars.com
Hand assembled in England By:
Award-Session, 34 Belvedere, Basingstoke, Hampshire, RG24 8GB, UK
Tel. +44 (0)1256 477 222 - Email. help@award-session.com
Website: www.award-session.com
PIN 2 - Hot/Signal
PIN 3 - Ground
