Procycle WR250RX Installation Instructions

Parts Supplied

We highly recommend that you thread lock all bolts prior to installation. Periodically re-check
all nuts and bolts to maintain rigidity and structural integrity.
1. Remove the stock tool holder on the left side of the motorcycle.
2. Remove the Helmet Lock.
3. Mount the Tool Tube Mounting Bracket to the lower mount used for the stock tool tube as
shown below. Use the 6x20mm bolt, 6x12mm washer and 6mm nylock nut provided in the kit.
All appropriate safety equipment and gear must be used during the installation of this or any ProCycle product including any
time you work on a vehicle. ProCycle accepts no responsibility for injuries or damage incurred during the installation of any products.

WR250RX Tool Tube Installation Notes

Quantity Description
1 6mm x 20mm Bolt
1 8mm x 16mm Bolt
6mm Nylock Nut
1
1 6mm x 12mm Washer
Spacer
1
1 Tool Tube Clamp
1 Tool Tube Mounting Bracket
3" x 13.25" Black ABS Pipe
1
2 Tube Plug
1 Installation Instructions
