Summary of Contents for Verizon Wireless FT2260
- Page 1 USER MANUAL VERIZON WIRELESS HOME PHONE CONNECT...
- Page 2 Welcome to Verizon Wireless Thank you for choosing Verizon Wireless Home Phone Connect. You’re now connected to the power of America’s most reliable wireless network. This guide will help you understand your new wireless device and all the things you can do with it. So let’s get started.
-
Page 3: Table Of Contents
Contents 1 Introduction....................................1 Package Contents................................1 Top View ....................................2 Bottom View ..................................3 2 Installation..................................... 4 Installing the Battery ..............................4 Installing the Antenna ..............................5 Installing the Power Adapter............................5 Connecting the Device to a Telephone ........................6 Mounting the Device.............................. -
Page 4: Introduction
Package Contents The package should contain the following item s. Ple ase contact Ve rizon Wireless if any of the item s are missing or damaged. Verizon Wireless Home Phone Connect Antenna Battery User Manual Quick Reference Product Safety Guide... -
Page 5: Top View
Top View Note: The figures are only for your reference, the actual shape and color of the product may differ slightly. Power on/off switch Antenna port Telephone port 1 Signal strength indicators Telephone port 2 Battery indicator USB port* Power indicator DC 12V power port Voice mail indicator * Note: Never place a USB-based device into the USB port of the Home Phone Connect under any... -
Page 6: Bottom View
Bottom View Battery cover Battery slot Battery port Wall-mounting brackets... -
Page 7: Installation
Installation Installin g the Battery Note: The system will stop charging the battery when the ambient temperature is o utside of the ° ° temperature range allowed for charging (14 F to 113 When the power adapter is connected, the battery will automatically charge. When fully charged, the battery will automatically stop charging. -
Page 8: Installing The Antenna
Installing the Antenna Make sure the device is turned off. Align the antenna with the antenna port on the device as illustrated below. Screw the antenna into the port, ensuring that the connection is secure. Installing the Power Adapter Under normal usage, the device relies on the external power adapter for its power supply. Insert the power adapter into the DC input port, and plug the unit into an AC wall outlet. -
Page 9: Connecting The Device To A Telephone
Connecting the Device to a Telephone The device provides two telephone ports. The ports use the same telephone number. Plug one end of a telephone cable (RJ11) into a telephone port and the other end into the back of a home telephone or home telephone base unit. -
Page 10: Mounting The Device
Mounting the Device Horizontal Mounting Place the device on a smooth surface with good ventilation. Place it at least 4 inches away from other objects. Vertical Mounting Fix two wall screws into the wall with the screw heads extending approximately 0.1 inches from the surface of the wall. -
Page 11: General Functions
General Functions Powering on the Device ss t button to pow er on the device. When the device is on, the power indicator will be blue. No : Press and hold the button for 1 second to power off the device. Activating the Device If y ur device h... -
Page 12: Understanding The Indicators
Understanding the Indicators The table below describes possible states for each of the device indicators. Icon Indicator Status Blinking Blue New Message Voice mail Blue Full Charge Blinking Blue Partial Charge Battery Blinking Red Low Charge Both Blue Strong One Blue Moderate Signal Strength One Blinking Blue... -
Page 13: Making A 3-Way Call
Making a 3-Way Call You can talk with two parties at the same time by using the 3-way call feature on your Home Phone Connect. Airtime and other charges, which may include toll or long distance charges will apply for all simultaneous calls. -
Page 14: Using Voice Mail
Important Facts About Your Home Phone Connect Dialing Your Verizon Wireless Home Phone Connect requires 10-digit dialing. Please dial the three digit Area Code when calling local and long distance numbers. Your Verizon Wireless Home Phone Connect does not support rotary or pulse dialing phones. -
Page 15: Assistive Communication Devices
Your Verizon Wireless Home Phone Connect does not support incoming or outgoing fax service. Home Security Systems Your Verizon Wireless Home Phone Connect may not be compatible with certain Home Security systems. Please check with your security system provider to confirm the compatibility requirements of your Home Security system. -
Page 16: Troubleshooting
Check to make sure the telephone cable is securely plugged in (refer to page 6 of the User Manual). Check to make sure you are not roaming outside of the Verizon Wireless network. How do I check my voice messages? Dial * 8 6 to access your voice mail messages. - Page 17 Can I use my telephone answering device instead of voice mail? Yes. Set the answering device to fewer rings in order to pick up the call before Verizon Wireless voice mail. Alternatively, turn off your home answering machine or increase the number of rings if you would like to use the Verizon Wireless voice mail service.
- Page 18 My Caller ID does not display the name of the incoming caller. The Home Phone Connect service is no t currently compatible with calling name delivery. Caller name information will be displayed if the inco ming caller's contact information is saved in your home phone address book.
