DESCRIPTION:
Singer Model 106/206-DW is a deep well pump
control valve designed to eliminate starting and
stopping surges of deep well pumps.
The main valve is a single seated, hydraulically
operated, diaphragm actuated, globe or angle pattern
valve.
The main valve is controlled by a solenoid
pilot valve, utilizing line pressure for operation. The
valve has a Limit Switch, which shuts down the pump
when the pumping cycle is completed.
DESCRIPTION OF OPERATION:
Model 106/206-DW is installed in a tee between the
pump discharge and the check valve. The pump is
started and stopped on an open valve. The discharge
may be returned to the well or to an open drain.
The valve is wide open when the pump is off. When
the pump is started, the valve discharges initial rush
of sand and water from the pump column to waste.
Solenoid Valve (7) is energized and the Main Valve
starts closing. The closing speed is adjustable. Main
Valve (1) closes slowly; flow into system increases
gradually, preventing starting surges.
On shutdown Solenoid Valve (7) is de-energized.
Main Valve (1) opens slowly.
adjustable. While the Main Valve is opening, Limit
Switch (9) keeps the pump running.
Valve opens, flow into the system decreases
gradually. Pump stopping surges are prevented.
When the Main Valve is almost fully open, Limit
Switch (9) stops the pump.
INSTALLATION:
1. See 106/206-PT "Installation".
2. Connect the operating pressure connection (5) to
the header, downstream of the pump check
valve. (See schematic).
SINGER MODEL 106/206-DW
Double Chamber, Bypass Pump Control Valve
Deep Well Pump Control Valve
Installation, Operating and Maintenance Instructions
Schematic A-7514C
Opening speed is
As the Main
IOM A-7514C
Page 1 of 2
NOTE REGARDING SIZE AND CAPACITY OF
THIS CONNECTION:
Use 3/8" copper tube up to 10 ft of distance, 1/2"
copper tube for longer runs. All fittings and drilled
holes must be full nominal size for reliable
operation.
3. Connect Solenoid Valve (7) and Limit Switch (9)
to the electrical system. Check Solenoid Valve
name plate for correct pressure. Check side of
coil for correct voltage. Connections in the Limit
Switch must be to common and normally closed
terminals. See 'Suggested Wiring Diagram'.
4. If the outlet pipe has a submerged discharge or
any other reason to develop sub-atmospheric
pressure, a vacuum breaker is recommended to
reduce cavitation damage.
ADJUSTING PROCEDURE:
1. Close Opening Speed Control (8) and Closing
Speed Control (2).
2. Start the pump.
3. Open Closing Speed Control (2) slowly until
desired closing speed is achieved.
4. Turn the pump switch to off position. The pump
should continue to run.
5. Open Opening Speed Control (8) slowly until
desired opening speed is achieved.
6. When the valve is almost fully open, Limit Switch
(9) should stop the pump. If the pump does not
stop, adjust the Limit Switch.
7. Excessively long opening and closing times
should be avoided because this may affect the
pump motor and may also cause plugging of the
speed controls by any solids in the water.
August 2004
th
12850-87
Avenue
Surrey, BC. Canada. V3W 3H9
Ph: 604-594-5404
Fx: 604-594-8845
www.singervalve.com
