Dutton-Lainson Strongarm SA7000AC Owner's Manual

OWNER'S
MANUAL
MODELS SA5000AC, SA7000AC,
SA9000AC, SA12000AC
WARNING:
ATTEMPTING TO INSTALL, OPERATE OR SERVICE THE STRONG RM
ELECTRIC WINCH. FAILURE TO COMPLY WITH INSTRUCTIONS COULD RESULT
IN SERIOUS OR FATAL INJURY. RETAIN INSTRUCTIONS FOR FUTURE REFERENCE.
electric Winch rating*
5000
4500
4000
3500
3000
2500
2000
1500
1000
500
10
LENGTH oF CaBLE oN REEL (FT.)
guide to rolling load capacitY**
Maximum weight in pounds and kilograms rolling load.
Model
5% 10%
(3°) (6°)
8,000 lbs. 6,000 lbs. 4,000 lbs. 3,100 lbs. 2,200 lbs. 1,800 lbs.
SA5000AC
3,629 kg 2,722 kg 1,814 kg
12,000 lbs. 9,000 lbs. 6,100 lbs. 4,600 lbs. 3,300 lbs. 2,700 lbs.
SA7000AC
5,443 kg 4,082 kg 2,767 kg
18,000 lbs.13,500 lbs. 9,100 lbs. 6,900 lbs. 5,000 lbs. 4,100 lbs.
SA9000AC
8,165 kg 6,124 kg 4,128 kg
26,700 lbs. 20,100 lbs.13,600 lbs. 10,300 lbs. 7,400 lbs. 6,100 lbs.
SA12000AC
12,111 kg 9,117 kg 6,169 kg
(*) Load capacity (dead weight) is a measure of actual maximum force to which the
winch system may be subjected.
(**) all capacities shown are with 15' of cable on the reel and 10% rolling friction factor.
For full reel of cable adjust capacities according to graph above. Note 5% incline is
one-half foot rise in ten feet.
READ INSTRUCTIONS CAREFULLY BEFORE
Winch ratings
20 30 40
PERCENT INCLINE
20% 30% 50%
(11°) (17°) (26°)
1,406 kg 998 kg
2,087 kg 1,497 kg 1,225 kg
3,130 kg 2,268 kg 1,860 kg
4,672 kg 3,357 kg 2,767 kg
®
double line operation
Models Sa7000aC and Sa12000aC are factory
equipped with a pulley block and hook and 50' of
cable for double line operation. This increases the
pulling capacity of the winch as shown, however,
care must be taken to allow adequate motor cool-
ing. Note that with double line, a pull of 25' requires
reeling in 50' of cable.
For intermittent use only. Ratings at left are based
on 10' pull. For longer pulls motor cooling periods
must be allowed.
MaXIMuM CoNTINuouS RuN TIME 3 MINuTES
caution: continuous running in
50
eXcess of 3 Minutes Will daMage Winch
Motor.
Load
70%
CaPaCITY*
(35°)
1,200 lbs.
816 kg 544 kg
1,800 lbs.
816 kg
2,700 lbs.
1,225 kg
4,000 lbs.
1,814 kg
1
120 Volt C
ELECTRIC WINCHES
approXiMate load speed
(ft./Min.)
No Load
Full Empty
Reel Reel
SA5000AC 35 16
SA7000AC 17.5 8
SA9000AC 18 6
9 3
SA12000AC
Warning: not to be
used as a hoist for
lifting, supporting or
transporting people or
loads over areas Where
people could be present!
FuLL Load
Full Empty
Reel Reel
16 9
9.5 6
7 3.5
4 2
