Summary of Contents for American Diagnostic Corporation Satin
- Page 1 Satin Standard, ® Fiber Optic and Disposable Laryngoscope Blades and Handles Directions for Use ®...
-
Page 2: Device Description And Intended Use
Thank you for choosing an ® Satin™ Laryngoscope. Device Description and Intended Use A laryngoscope is a two-part, hand-held device consisting of a handle that contains bat- teries and a detachable blade. Laryngoscopes are designed to provide illumination within the larynx during the process of performing intubations. This instruction book cov- ers standard, fiberoptic, and disposable laryngoscopes. - Page 3 (See Figure 1). On Position Figure 1 Compatibility/Standards Standard ADC ® Satin ™ Laryngoscopes conform to current ISO 7376 standards. They are compatible with virtually all major brands of standard illumination hook-on blades and handles. Fiberoptic ADC...
- Page 4 Cleaning, Disinfecting, and Sterilization Procedures ® Satin™ Laryngoscope blades are crafted from rugged stainless steel. ADC ® Dispos- able Fiberoptic Laryngoscope blades are crafted from poly-carbonate, and are for single use only and should not be cleaned or sterilized. Reusable handles are machined from chrome- plated brass or anodized aluminum.
- Page 5 Basic Cleaning Procedure for Standard and Fiberoptic Blades: Prepare a Klenzyme ® , Manu-klenz ™ , or equivalent cleaning solution as per manufac- turer’s instructions and soak for ten minutes. Rinse devices with lukewarm running tap water for one minute to remove any residual detergent after cleaning. Dry with a clean, lint-free cloth.
-
Page 6: Repair/Maintenance
High-Level Disinfection for Standard and Fiberoptic Handles: To achieve high-level disinfection, a 2.4% glutaraldehyde solution (Cidex or equivalent) ® must be prepared at 77°F (25°C) to the manufacturer’ s instructions. The end caps of the handles, lamp cartridge and bulb, and batteries must be removed. Both the end caps and handles should be fully immersed in the disinfectant for a minimum of 45 minutes. - Page 7 Battery Replacement: (4067F Stubby Handle) 1) Unscrew bottom cap of handle and remove battery insert. Main Main Handle Handle 2) Replace with appropriate size batteries. Insert 1 battery positive end first and the other negative end first into battery insert, paying Battery Battery Insert...
-
Page 8: Test Procedures
CAUTION: Be sure lamp’s glass surface is clean and free from fingerprints after assem- bly. If necessary, the glass may be cleaned with a soft cloth or cotton ball moistened in alcohol. Fiberoptic Light Guide Replacement: 1) Loosen the locking screw with a screwdriver. (Note: This screw is NOT designed to be completely removed. -
Page 9: Replacement Parts Chart
REPLACEMENT PARTS CHART DESCRIPTIONS STANDARD MODELS Standard Standard Laryngoscope Blade Replacement Lamp Item Mac 0 4070 4500 Mac 1 4071 4500 Mac 2 4500 4072 Mac 3 4073 4501 Mac 4 4074 4501 Miller 00 4080-0 4500 Miller 0 4080 4500 Miller 1 4500... - Page 10 REPLACEMENT PARTS CHART DESCRIPTIONS STANDARD MODELS Laryngoscope Fiberoptic Fiberoptic Fiberoptic Light Item Replacement Lamp Blade Guide Mac 0 4070F 4070FLP-00 Mac 1 4071F 4071FLP-00 Mac 2 4072F 4072FLP-00 Mac 3 4073F 4073FLP-00 Mac 4 4074F 4074FLP-00 Miller 00 Miller 0 4080F 4080FLP-00 Miller 1...
- Page 11 REPLACEMENT PARTS CHART DESCRIPTIONS SPU MODELS Fiberoptic Laryngoscope Blade Item Mac 0 4071D-20 Mac 1 4072D-20 Mac 2 4073D-20 Mac 3 4074D-20 Mac 4 4080-0D-20 Miller 00 4080D-20 Miller 0 4081D-20 Miller 1 4082D-20 Miller 2 4083D-20 Miller 3 4084D-20 Miller 4 Wisconsin 0 Wisconsin 1...
-
Page 12: Limited Warranty
LIMITED WARRANTY American Diagnostic Corporation (ADC ) warrants its products against defects in ® materials and workmanship under normal use and service as follows: 1. Warranty service extends to the original retail purchaser only and commences with the date of delivery. - Page 13 Inspected in the U.S.A. Reusable models: Made in Pakistan Disposable models: Made 55 Commerce Drive in Taiwan/China Hauppauge, NY 11788 U.S.A. tel: 631-273-9600 toll free: 1-800-232-2670 fax: 631-273-9659 ADC (UK) Ltd. Unit 6, PO14 1TH www.adctoday.com United Kingdom info@adctoday.com Printed in the U.S.A. IB p/n 9358-00 rev 14...
