Intex Pool Volleyball Set Owner's Manual

(99IO) ENGLISH POOL VOLLEYBALL SET MANUAL (FOR OVAL POOL) SIZE: 4.875" X 7.25"
INTEX OWNER'S MANUAL
®
Pool Volleyball Set for Intex
IMPORTANT SAFETY RULES
Read, Understand and Follow All Instructions Carefully Before Installing and Using this Product.
WARNING
• POOL AND POOL ACCESSORIES ARE TO BE ASSEMBLED AND DISASSEMBLED BY ADULTS ONLY.
• USE ONLY UNDER COMPETENT SUPERVISION.
• WHEN NOT IN USE REMOVE FROM THE POOL AND STORE IN A SAFE PLACE INDOORS.
• DO NOT USE DURING WINDY AND GUSTY DAYS.
• FOLLOW THESE RULES TO AVOID SERIOUS INJURY OR PROPERTY DAMAGE.
• USE ONLY MANUFACTURER SUPPLIED BALLS. PROFESSIONAL ATHLETIC BALLS ARE NOT
RECOMMENDED.
• YOU MUST FIRST SET UP AND FILL THE POOL WITH WATER FOLLOWING THE POOL OWNER'S
MANUAL BEFORE INSTALLING.
• DO NOT CLIMB, HANG, PULL, PUSH OR GRAB ANY PART OF THE STRUCTURE. THE STRUCTURE
IS NOT DESIGNED TO SUPPORT USER BODY WEIGHT.
• REMOVE THE STRUCTURE BEFORE PLACING A POOL COVER OVER THE POOL.
ALWAYS FOLLOW ALL SAFETY RULES. CARELESSNESS, OR LACK OF ATTENTION, CAN HAVE
SERIOUS CONSEQUENCES, SUCH AS PARALYSIS OR OTHER PERMANENT INJURIES.
For illustrative purposes only.
SAVE THESE INSTRUCTIONS
Page 1
08/12/2010
99IO
Oval Pools
®
099IO-R0-1108
(99IO) ENGLISH POOL VOLLEYBALL SET MANUAL (FOR OVAL POOL) SIZE: 4.875" X 7.25"
PARTS LIST
2
1
5 6
9 10
NOTE: Drawings for illustration purpose only. May not reflect actual product. Not to scale.
PARTS REFERENCE
Before assembling your product, please take a few minutes to check the contents and become
familiar with all the parts.
10
8
7
1
3
2
REF. NO. DESCRIPTION
1 CONTROL SCREW
2 POLE BRACKET
3 X-LONG PIN (WITH 2 EXTRA)
4 U-BOLT A
5 U-BOLT
6 NUT
7 POLE
8 VOLLEYBALL POLE END PLUG
9 VOLLEYBALL NET FASTENER
10 VOLLEYBALL NET
VOLLEYBALL
11
SAVE THESE INSTRUCTIONS
Page 2
08/12/2010
99IO
3 4
7 8
11
9
6
4
5
QTY. SPARE PARTS NO.
4 10545
2 10684
4 10110
2 10686
2 10544
8 10657
2 10685
2 10539
4 10535
1 10866
1 10541
