Item No.: PL730
Technical Data
Dimensions
Material
Zinc alloy housing and handle
Mechanical override key
Fixing screws and cam
Input Voltage
DC3V
Battery
2 X AA alkaline batteries
Service life 60,000 locking cycles
≤100uA
Static Power
≤170mA
Dynamic Power
Use condition
Temperature: -15℃~65℃；
Humidity: 5%~95%
Features:
Works with most Mifare solutions @ 13.56MHz
Three level system for user administration
Quick and easy operation
No external programming devices needed
LED in 2 colors for lock status (green/red)
Application for metal, wooden and plastic doors
Can be used right/left handed on door thickness up to 20mm
www.qilocks.com
RFID Cam Lock Product Guide
sales@qilocks.com
Induction Area
Emergency opening
+44 (0)20 8906 6881
Handle
Advertisement
Table of Contents
Summary of Contents for QiLocks PL730
- Page 1 RFID Cam Lock Product Guide Item No.: PL730 Technical Data Dimensions Material Zinc alloy housing and handle Mechanical override key Fixing screws and cam Induction Area Input Voltage DC3V Battery 2 X AA alkaline batteries Service life 60,000 locking cycles Handle ≤100uA...
- Page 2 The RFID cards activate various functions when they are presented to the lock. Programming Main-Admin cards: - Hold the Main-Admin card in front of the lock for 1~2 seconds (green light flashes 3 times) wait approximately 5 seconds, setup successfully. www.qilocks.com sales@qilocks.com +44 (0)20 8906 6881...
- Page 3 - After that, the user card to be deprogrammed is held for approximately 5 seconds in front of the lock until it flashes red twice, remove the card - Repeat this procedure with all user cards that you would like to deprogram. www.qilocks.com sales@qilocks.com +44 (0)20 8906 6881...
- Page 4 -The alarm will sound if the battery is low and the LED will flash red 5 times warning users to replace the battery soon. Changing the Battery Remove fixing screw Rotate the lock down over the edge of door Take out the batteries Put in the new batteries and screw lock back into place www.qilocks.com sales@qilocks.com +44 (0)20 8906 6881...
