NAPCO GEM-PX Installation Instructions

R
333 Bayview Avenue
Amityville, New York 11701
For Sales and Repairs, (800) 645-9445
For Technical Service, (800) 645-9440
Publicly traded on NASDAQ Symbol: NSSC
© NAPCO 2004

GENERAL DESCRIPTION

The GEM-PX is a NAPCO proprietary proximity card reader
which combines with the GEM-PXCV cover to provide com-
plete system status using indicator LED's. The GEM-PX
reader can only be used with GEM 36-bit proprietary prox-
imity cards. The GEM-PX reader consists of the proximity
reader module, which is fully encapsulated in weather resis-
tant potting and the snap on GEM-PXCV cover which
houses additional LED's. The multicolored LED on the
GEM-PX provides standard visual feedback as to access
condition (door "locked" or "unlocked"), and the additional
LED's in the GEM-PXCV cover provide feedback as to sys-
tem condition (system "armed" or "disarmed"). Together,
the GEM-PX and GEM-PXCV is an indoor/outdoor prox-
imity card reader providing potted electronics, low power
consumption and durability all in a small, easy to install
package.

SPECIFICATIONS

12V Nominal, 50mA standby current.
LED Indications
The GEM-PX reader contains a multicolored LED which
Access
Status LED
(see table 1)
System
Status LED's
(see table 2)
Stealth Mode is used to hide the ACM's Armed and Status
LEDs. When Stealth Mode is enabled, the GEM-PXCV
Table 1: Access Status LED (Top)
LED INDICATION
Steady Red
Steady Green
Momentary Green
Alternating Green & Red (Downloading PCD-Windows Program to ACM)
Table 2: System Status LED's (Bottom)
LED INDICATION
Steady Red
Red LED is off
Blinking Red
Steady Green
Green LED is off
Installation Instructions
provides visual feedback
as to access condition
when access cards are
presented to the reader.
Table 1 below displays
the LED indications and
their meanings.
The GEM-PXCV pro-
vides two LED's to indi-
cate system condition,
as displayed in Table 2
below:
ACCESS CONDITION
Door Locked
Door Unlocked
Card Read--Door Remains Locked
SYSTEM CONDITION
System Armed
System Disarmed
System in Alarm
System Ready to Arm
System Not Ready to Arm
GEM-PX
Proximity Reader
system status LEDs are normally off but are turned on for 1
minute by any of the following events:
• Press a request to exit button
• Press a request to arm button
• Present a valid ARM/DISARM or ARM card to the
reader
When Stealth Mode is disabled ("normal operation"), the
LED's are always enabled and mimic the Keypad Status
LEDs for the following functions only: Armed, Disarmed,
Ready to Arm, Not-Ready to Arm and Alarm. Note: When
the system is in alarm, Stealth Mode is disabled. "Access
Only" cards do not affect the status of Stealth Mode.
MOUNTING THE GEM-PX
Table 3: Proximity Card Reader Connections
GEM-ACM1D Termi-
nal Number
17 (+)
18 (-)
19
20
21 (-)
22 (-)
23 (-)
(Not Used)
(Not Used)
* Tamper Connection not available on HID 6005B
Be sure to place jumper JP1 in correct configuration for 5 volt of 12 volt reader
operation.
Table 4: GEM-PX Wire Connections
GEM-PX Wires
Red
Orange Active Low Red
Green Status Green LED
Before mounting the card reader, always plan ahead and deter-
mine the route all wires will follow before drilling into wall mount-
ing surfaces. For more information regarding various system
designs, refer to WI1121 for complete installation instructions.
Install the GEM-PX as follows:
1. Determine mounting location.
(Figure 1) and a pencil, lightly mark the location of the two
mounting holes and the two wire feed holes.
2. Route the Reader Wires. The minimum number of wires
required to activate the reader are displayed in Table 3.
Determine which wires will be needed and plan how these
wires will be accessed from behind the mounting location.
3. Install dry wall mounting hardware. Use hardware such
as molly bolts, toggle bolts or other anchoring devices.
Drill the smallest hole needed for the device. Warning:
Use caution when drilling holes--there may be high voltage
wiring in wall.
4. Drill wire feed holes. Minimum size for the top feed hole
WI1269B 10/04
GEM-ACM1D Terminal HID Model 6005B (Prox Point
Description
Reader Power
Reader Power Black (- Ground) & (Shielded
Reader Data 1
Reader Data 0
Red LED
Red & Green LED Orange (Green LED)
Reader Sounder
(Not Used)
(Not Used) Violet (Card Present)
GEM-ACM1D GEM-ACM1D
Terminal Terminal Number
Description
Reader Power 17 (+)
30
Armed LED
31
Using the template
Plus ) Wires
Red (+ DC)
Ground)
White (Data 1)
Green (Data 0)
Brown (Red LED)
Yellow (Beeper)
Blue (Hold)
GEM-2D Terminal
Number
35 (+)
48
49
1
