POWERbreathe K-Series Quick Start Manual

Hide thumbs Also See for K-Series:

The quick start guide is provided for quick reference only. We recommend that you read the full

manual before starting training for the first time.

Connecting POWERbreathe K-Series device to PC

To connect the POWERbreathe K-Series device to your PC, You need to have installed the Breathe-

Link software and relevant drivers first.

1. Using the USB cable supplied, connect the mini USB end of the cable to the POWERbreathe

K-Series device at the charging port.

2. Connect the standard USB end of the cable to your PC USB ports.

3. Ensure that the POWERbreathe K-Series device is switched OFF. The POWERbreathe LCD

should be blank. (Please note in some instances the Red Charge light may be on.

start the Breathe-Link application).

4. Installing the software and drivers for the first time wait for 10 seconds so that the PC can

establish communications with the relevant device drivers. For windows

windows message should appear notifying you that a new USB hardware was found. After

the initial connection, the wait time should be reduced to no more then 5 seconds.

5. Start up Breathe-Link software, at this stage the application will initialize the POWERbreathe

K series device. The Breathe-Link screen will appear on the

Breathe-Link application will show an Breathe-Link logo screen and the valve will move

to the open position indicating that both the POWERbreathe K-Series device and the

Breathe-Link software are synchronised. The connect button will also change text to

disconnect indicating that the POWERbreathe K-Series device and Breathe-link has

successfully connected.

If you receive a message stating that no POWERbreathe K-Series device is not

connected then go to section 3.3 Breathe-Link Driver Information.

Version 2.0 | May 2012

Breathe-Link Quick Start Guide

Figure 1 Connect POWERbreathe K-Series to PC

POWERbreathe K-Series device.

Public

It is OK to

2000 or later a

Page 1 of 3
