Installation, Inspection, Operation
& Maintenance Guide
Model 890CL/890CR Coupling
IMPORTANT
Read these instructions completely before installing, using or
attempting to repair this product. If you have any questions,
call Premier at (800) 255-5387 or (503) 234-9202.
Advertisement
Summary of Contents for Premier Manufacturing Co. 890CR
- Page 1 MANUFACTURING CO. THE FIRST NAME IN QUALITY COUPLINGS Installation, Inspection, Operation & Maintenance Guide Model 890CL/890CR Coupling IMPORTANT Read these instructions completely before installing, using or attempting to repair this product. If you have any questions, call Premier at (800) 255-5387 or (503) 234-9202.
- Page 2 Selecting The Right Equipment Whatever your application, selecting the proper equipment for the job is very important� Proper selection along with regular inspection and maintenance will help keep operating costs minimal while providing long life to each component� Below are general guidelines for selecting Premier Couplings and Drawbar Eyes� If you feel that your application is unique, please give Premier a call so that we may help you through the selection process�...
- Page 3 Selecting The Right Equipment Understanding Premier Load Specifications Each Premier product undergoes extensive design and testing prior to being introduced� We use the latest in Computer Aided Design and Analysis Software as well as physical destructive tests� Premier’s published load specifications are the maximum load a given product or part will withstand without failure�...
- Page 4 Selecting The Right Equipment Coupling - to - Drawbar Eye, Cross Reference Chart Drawbar Eyes • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •...
-
Page 5: Replacement Part Information
Minimum Eye Opening: 2 3/8 in. (60 mm) product. Overloading or abuse may lead to Unit Weight: 62.2 lbs. (28.2 kg) property damage, severe injury, or death. 890CR STANDARD INSTALLATION DRAWING 890CR 891P Pin 896 Handle 891Handle 25/32 890C 7 9/32... -
Page 6: Installation
Model 890CL/890CRCoupling PARTS Coupling: 890CL / 890CR Coupling 890C: 890CL and 890CR sold together ACCESSORIES Optional Accessories: - Bolt Kit 507: Four 3/4-10 x 2 3/4 in. grade-8 bolts and 3/4-10 grade-C locknuts. - 14014 Wear Gage 14014 (2 1/8 in.): To determine hook wear limits. -
Page 7: Operation
6. The 890CL Coupling is now fully open and position. ready to be coupled. 6. The 890CR Coupling is now fully open and ready to be coupled. Page 7 PREMIER MANUFACTURING COMPANY... - Page 8 Model 890CL/890CRCoupling INSPECTION / MAINTENANCE / OPERATION CLOSING Coupling Latch: 1. Verify that the 890CL/890CRCoupling is in the 3. Visually verify that the 891 and 896 Handles FULLY OPEN POSITION prior to connecting are in their locked close, upward most positions to a drawbar eye.
- Page 9 ATTENTION ! End Users must read and follow this information. DISTRIBUTORS & OEM’S: Please ensure that your customers are made aware of the following information on this page. (1) VERIFY THAT BOTH COUPLING’S AND (8) DO NOT APPLY LUBRICANTS TO THE COUPLING DRAWBAR EYE’S RATED CAPACITIES MEET HOOK OR DRAWBAR EYE LOOP, AS THEY YOUR APPLICATION(S) REQUIREMENTS.
- Page 10 Model 890CL/890CRCoupling Installation, etc. Revised: 05/16 WARRANTY: We warrant all Premier products to be free from defects in material or workmanship for one year. We will repair or replace, at our option, any Premier product which our examination reveals to be defective, provided that the product is returned to our factory, at Tualatin, Oregon transportation prepaid, within one year of purchase by the first retail purchaser.
