Speed by spectre 9922 Installation Instructions

Intake

Table of Contents

Download this manual

Intake Installation Instructions P/N 9922

Legal for use on pollution

controlled vehicles

C.A.R.B E.O.# D-629-1

for applications listed above

For filter reorders ask at the

special order counter of your

local parts store or call:

1-800-821-4868

ask for P/N 889882

99-04 Ford F250 7.3-V8 td

99-04 Ford F350 7.3-V8 td

99-04 Ford Excursion 7.3-V8 td

Tools Required:

•

13mm socket or wrench

•

8mm socket or wrench

•

10mm socket and wrench

•

5/16" nut driver or Flat

Blade Screwdriver

1- Filter shield

1- Air filter

1- Intake tube

1- 4" coupler

1- Rubber vibration mount

2- M8 fender washers

2- M8 lock nuts

1- Plug

2- Grommets

3- 4" hose clamps

1- Rubber seal

1- Rubber liner

Table of Contents

Do you have a question about the 9922 and is the answer not in the manual?

Page 1 Intake Installation Instructions P/N 9922 Year/Make/Model/Engine 99-04 Ford F250 7.3-V8 td 99-04 Ford F350 7.3-V8 td 99-04 Ford Excursion 7.3-V8 td Tools Required: Parts List • 13mm socket or wrench 1- Filter shield • 8mm socket or wrench 1- Air filter •...
Page 2 Step 1 Safety First! Before you begin disconnect the negative battery terminal. Verify all components listed are present before beginning the Step 3 Step 2 installation. Remove the OE intake assembly Start by loosening the clamps out of the engine. securing the OE intake tube to the turbo inlet and the air box.
Page 3 Step 12 Step 11 Step 10 Attach the rubber vibration Place coupler and clamps over Insert the heat shield assembly mount to the housing, secure the turbo inlet. Do not tighten into the battery tray. Secure with with the supplied nut and clamps at this time.
Page 4 Spectre Performance Technical Department by email - Tech@spectreperformance.com or by phone 1-800-821-4868 Monday thru Thursday 6:00am to 4:30pm PST. Product Info: Performance Air Induction System P/N 9922 (909) 673-9800 www.spectreperformance.com © 2010 SPECTRE PERFORMANCE Made in China (P) REV. 5/10...
